FRAME - CHASSIS для Polaris 340 (S08NB3AS) - 2008 года выпуска
-
№АртикулНазвание
-
-1014086-309 ASM-CHASSIS, SVC, EDGE, STD, NAT (INCL. 26, 30)ASM-CHASSIS, SVC, EDGE, STD, NAT (INCL. 26, 30)
-
17621432 RIVET, 3/16X.402RIVET, 3/16X.402
-
25431385 GUIDE, RECOILGUIDE, RECOIL
-
35222687-067 BRKT, ROPE GUIDE, BLACK.BRKT, ROPE GUIDE, BLACK.
-
45246330 BRKT-OIL TANK/HOSE SUPPORTBRKT-OIL TANK/HOSE SUPPORT
-
57080934 CAPLUG-1 5/8''CAPLUG-1 5/8''
-
65246177 BRKT-AIRBOXBRKT-AIRBOX
-
77080592 CAPLUG, 3/4''CAPLUG, 3/4''
-
85812290 GASKET-SEAT BASEGASKET-SEAT BASE
-
95812360 GASKET-SEAT BASE 1/4''GASKET-SEAT BASE 1/4''
-
107517441 SCREW, .75SCREW, .75
-
117621472 RIVETRIVET
-
127512232 BOLTBOLT
-
137552801 WASHER, SPRING LOCKWASHER, SPRING LOCK
-
147558301 WASHER, FLATWASHER, FLAT
-
152632165-309 ASM., BUMPER, REARASM., BUMPER, REAR
-
165433961-070 FLAP-SHORT, BLACK, EDGEFLAP-SHORT, BLACK, EDGE
-
172670133 REFLECTOR ASM, REDREFLECTOR ASM, RED
-
182632443-070 ASM-SNOWSKIRT/REFLECTOR, BLACK, LEFT HANDASM-SNOWSKIRT/REFLECTOR, BLACK, LEFT HAND
-
182632444-070 ASM-SNOWSKIRT/REFLECTOR, BLACK, RIGHT HANDASM-SNOWSKIRT/REFLECTOR, BLACK, RIGHT HAND
-
195245118 BRACE-TUNNEL ROLLBRACE-TUNNEL ROLL
-
205433150 STRAPSTRAP
-
217661637 RIVET, INTERLOCK, ZRIVET, INTERLOCK, Z
-
225246310 SUPPORT-FOOTREST, LEFT HANDSUPPORT-FOOTREST, LEFT HAND
-
225246311 SUPPORT-FOOTREST, RIGHT HANDSUPPORT-FOOTREST, RIGHT HAND
-
235245457 MOUNT-CONSOLE, TOE CLIP, LEFT HANDMOUNT-CONSOLE, TOE CLIP, LEFT HAND
-
235245458 MOUNT-CONSOLE, TOE CLIP, RIGHT HANDMOUNT-CONSOLE, TOE CLIP, RIGHT HAND
-
245245288 FOOTREST-LEFT HAND, .080FOOTREST-LEFT HAND, .080
-
245247205 FOOTREST-RIGHT HANDFOOTREST-RIGHT HAND
-
255246066 GUARD-BELTGUARD-BELT
-
262202059 KIT-MOUNT, TRAILING ARM, LEFT HANDKIT-MOUNT, TRAILING ARM, LEFT HAND
-
262202598 KIT-MOUNT, TRAILING ARM, RIGHT HANDKIT-MOUNT, TRAILING ARM, RIGHT HAND
-
277080416 PLUG, HOLEPLUG, HOLE
-
287661130 RIVET-3/16-.214-.420RIVET-3/16-.214-.420
-
297081076 PLUG-HOLE, 1.25PLUG-HOLE, 1.25
-
305132292 BULKHEAD-FRONT, MACHBULKHEAD-FRONT, MACH
-
314020139 CLIP, ROSEBUDCLIP, ROSEBUD
