STEERING- LOWER для Polaris 600 PRO-RIDE RUSH (2010) [S10BF6KEA] - 2010 года выпуска
-
№АртикулНазвание
-
17547423 NUTNUT
-
27555806 WASHER, FLATWASHER, FLAT
-
37061166 ROD ENDROD END
-
47547430 NUTNUT
-
55335697 TIE RODTIE ROD
-
67547431 NUT, LEFT HANDNUT, LEFT HAND
-
77061165 ROD END, LEFT HANDROD END, LEFT HAND
-
87519016 SCREWSCREW
-
97519017 SCREWSCREW
-
107061176 LINK, FIXEDLINK, FIXED
-
115136935 ROD, DRAG LINKROD, DRAG LINK
-
121823417 ASM., PITMAN ARMASM., PITMAN ARM
-
131823686 ASM, IDLER ARM (INCL. 14-16)ASM, IDLER ARM (INCL. 14-16)
-
145136662 BUSHING, REDUCERBUSHING, REDUCER
-
153514320 BEARING, BALLBEARING, BALL
-
165135452 SPACER, TUBE PITMAN/IDLER ARMSSPACER, TUBE PITMAN/IDLER ARMS
-
175437619 BUSHING, STEERING POSTBUSHING, STEERING POST
-
185132967 BRACKET, STEERING POSTBRACKET, STEERING POST
-
197519070 SCREWSCREW
-
202633977 ASM., BOOT, TIE ROD, LEFT HANDASM., BOOT, TIE ROD, LEFT HAND
-
202633978 ASM., BOOT, TIE ROD, RIGHT HANDASM., BOOT, TIE ROD, RIGHT HAND
-
217621457 RIVETRIVET
