COOLING SYSTEM для Polaris RANGER CREW 570-6 SAGE GREEN (R18RDA57A1) - 2018 года выпуска
-
№АртикулНазвание
-
15436936 TANK, SURGETANK, SURGE
-
27052065 FITTING, 90 DEGFITTING, 90 DEG
-
38450003-1525 LINE, FUEL, 1/4 ID(1525 CM.)LINE, FUEL, 1/4 ID(1525 CM.)
-
45261227 BRACKET, SURGE TANKBRACKET, SURGE TANK
-
55430743 CAP, OVER FLOW BOTTLE, DRILLEDCAP, OVER FLOW BOTTLE, DRILLED
-
65433774 PLUG, CAPPLUG, CAP
-
75810279 GASKET, OVERFLOW CAPGASKET, OVERFLOW CAP
-
87512084 SCREWSCREW
-
95414162 HOSE, BYPASS, 1 INCH, FORMEDHOSE, BYPASS, 1 INCH, FORMED
-
105414590 HOSE, BYPASS, 1/2 INCH, FORMEDHOSE, BYPASS, 1/2 INCH, FORMED
-
117052530 CONNECTOR, TEECONNECTOR, TEE
-
127080474 CLAMP, HOSECLAMP, HOSE
-
137080843 CLAMP, SPRINGBAND, BROWNCLAMP, SPRINGBAND, BROWN
-
145416387 HOSE-LOWER, RADHOSE-LOWER, RAD
-
155415053 HOSE, ENGINE OUTLET, REARHOSE, ENGINE OUTLET, REAR
-
165415054 HOSE, LOWER, ENGINE, SHORTHOSE, LOWER, ENGINE, SHORT
-
177518529 SCREWSCREW
-
181240899 CAP, PRESSURECAP, PRESSURE
-
195416386 HOSE-UPPER, RADHOSE-UPPER, RAD
-
207052028 GROMMET-FLANGED, .36X.56X1.06GROMMET-FLANGED, .36X.56X1.06
-
217052617 VALVE, PLASTIC RADIATOR/COOLER DRAINVALVE, PLASTIC RADIATOR/COOLER DRAIN
-
222413196 FAN-ASSEMBLY, SHROUDFAN-ASSEMBLY, SHROUD
-
235451221 BRACKET, COOLANT TUBEBRACKET, COOLANT TUBE
-
245261226 BRKT-RAD MNT, 3P, FS, GALVBRKT-RAD MNT, 3P, FS, GALV
-
257081192 CLAMP, HOSE, 25-40MMCLAMP, HOSE, 25-40MM
-
267516822 SCREWSCREW
-
277519001 SCREWSCREW
-
285141423 TUBE-COOLANT, 1 IN, FS, CREWTUBE-COOLANT, 1 IN, FS, CREW
-
291240955 ASM-RADIATOR (INCL. 18, 21)ASM-RADIATOR (INCL. 18, 21)
-
307512026 SCREWSCREW
-
315265091-329 BRKT-COOLANT TUBE MNT, BLACKBRKT-COOLANT TUBE MNT, BLACK
