BRAKE - FRONT MASTER CYLINDER для Suzuki VS800GL K5 - 2005 года выпуска
-
№АртикулНазвание
-
159100-38A02-999 CALIPER ASSY., FRONTCALIPER ASSY., FRONT
-
269100-38851 ...PISTON SET...PISTON SET
-
369100-38831 ......SEAL SET, PISTON......SEAL SET, PISTON
-
459145-16700 ...BOLT...BOLT
-
559143-16700 ...SPRING...SPRING
-
669141-45000 ...PIN...PIN
-
769142-45000 ...CLIP...CLIP
-
859151-38B01 ...COVER...COVER
-
959152-24A00 ...CAP, CALIPER...CAP, CALIPER
-
1059121-18410 ...BLEEDER...BLEEDER
-
1155156-66310 ...CAP...CAP
-
1259153-38B10 ...SCREW (4X6)...SCREW (4X6)
-
1359100-38890 PAD & SHIM SETPAD & SHIM SET
-
1459371-33410 ...SHIM...SHIM
-
1509106-10038 BOLT (10X33)BOLT (10X33)
-
1609250-08014 CAPCAP
