ASSEMBLY KIT для Tohatsu M4C - 2004 года выпуска
-
№АртикулНазвание
-
13F9B87100-1 Engine Short Block
incl D-S-Housing Gasket & Spark plugEngine Short Block
incl D-S-Housing Gasket & Spark plug -
2369-87122-1 Carburetor Repair KitCarburetor Repair Kit
-
2369-02011-0 * Gasket, Carburetor* Gasket, Carburetor
-
2369-03222-0 * 0-Ring, Float Cham ber* 0-Ring, Float Cham ber
-
2369-03293-1 * Gasket, Drain Screw* Gasket, Drain Screw
-
2922503-6412 * Screw* Screw
-
2369-03231-0 * Float* Float
-
2346-03232-0 * Arm Pin, Float Hinge* Arm Pin, Float Hinge
-
2369-03240-0 * Float Valve* Float Valve
-
2344-03244-0 * Clip* Clip
-
2921521-0408 * Screw* Screw
-
2346-03256-0 * Rubber Cap* Rubber Cap
-
2369-03303-0 * Diaohragm A"* Diaohragm A"
-
2369-03306-0 * Diaph ragm B"* Diaph ragm B"
-
2922553-6423 * Screw* Screw
-
2369-03302-0 * Gasket, Pump Cover* Gasket, Pump Cover
-
2369-03307-0 * Gasket, Pump Body* Gasket, Pump Body
-
2369-03182-0 * Gasket A", Carburetor Cover"* Gasket A", Carburetor Cover"
-
2369-03183-0 * Gasket B", Carburetor Cover"* Gasket B", Carburetor Cover"
-
2369-03186-0 * Screw* Screw
-
3369-87121-3 Power Head Gasket SetPower Head Gasket Set
-
3369-01005-1 * Gasket, Cylinder Head* Gasket, Cylinder Head
-
3369-01215-0 * Oil Seal, 10.1-25-8* Oil Seal, 10.1-25-8
-
3369-01214-0 * Gasket, Crank Case Head* Gasket, Crank Case Head
-
3369-00122-0 * Oil Seal, 20-47-9* Oil Seal, 20-47-9
-
3369-03222-0 * 0-Ring, Float Cham ber* 0-Ring, Float Cham ber
-
3369-03293-1 * Gasket, Drain Screw* Gasket, Drain Screw
-
3369-02011-0 * Gasket, Carburetor* Gasket, Carburetor
-
3369-61012-0 * Gasket, Drive Shaft Housing* Gasket, Drive Shaft Housing
-
4369S87301-2 Lower Unit Ass'v "S"
for Transom SLower Unit Ass'v "S"
for Transom S -
4369S87302-2 Lower Unit Ass'v "L"
for Transom LLower Unit Ass'v "L"
for Transom L -
5369S87323-1 Propeller Shaft Housing Ass'vPropeller Shaft Housing Ass'v
-
6369-87322-1 Water Pump Repair KitWater Pump Repair Kit
-
6369-65021-1 * Impeller Water Pump* Impeller Water Pump
-
6369-65022-0 * Key, Water Pump Impeller* Key, Water Pump Impeller
-
6369-65011-0 * Liner, Pump Case* Liner, Pump Case
-
6369-65018-0 * Gasket, Pump Case* Gasket, Pump Case
-
6369-65025-0 * Guide Plate, Water Pump* Guide Plate, Water Pump
-
6369-65029-0 * Gasket, Guide Plate* Gasket, Guide Plate
-
6369-65020-0 * Gasket, Pump Case Lower* Gasket, Pump Case Lower
-
6916113-0645 * Bolt
or 910103-0645* Bolt
or 910103-0645 -
6940113-0600 * Washer* Washer
-
7369-65231-0 Chrome Plate Water Pump KitChrome Plate Water Pump Kit
-
7369-65021-1 * Impeller, Water Pump* Impeller, Water Pump
-
7369-65238-0 * Liner, Pump Case* Liner, Pump Case
-
7369-65239-0 * Guide Plate, Water Pump* Guide Plate, Water Pump
-
7369-65018-0 * Gasket, Pump Case* Gasket, Pump Case
-
7369-65029-0 * Gasket, Guide Plate* Gasket, Guide Plate
-
8369-87321-0 * Lower Unit Gasket Set* Lower Unit Gasket Set
-
8332-60006-0 * Gasket, 8.2-14-2* Gasket, 8.2-14-2
-
8369-60111-0 * Oil Seal, 15-28-11* Oil Seal, 15-28-11
-
8345-65015-0 * 0-Ring, 3.2-48* 0-Ring, 3.2-48
-
8369-65018-0 * Gasket. Pump Case* Gasket. Pump Case
-
8369-65029-0 * Gasket. Guide Plate* Gasket. Guide Plate
-
8369-60223-0 * Oil Seal. 10-24-9* Oil Seal. 10-24-9
-
8369-65020-0 * Gasket. Pump Case Lower* Gasket. Pump Case Lower
-
8369-66021-1 * 0-Ring, 2.5-4.9* 0-Ring, 2.5-4.9
-
8332-66032-0 * 0-Ring, 2.4-15.5* 0-Ring, 2.4-15.5
-
9369S87314-0 Extension Housing Kit UL"
For Transom "UL"Extension Housing Kit UL"
For Transom "UL" -
103F9S87801-1 Decal SetDecal Set
-
11369S63010-1 Handle Ass'yHandle Ass'y
Все узлы модели:
- • ASSEMBLY KIT
- BRACKET REVERSE LOCK ARM
- CARBURETOR
- CYLINDER CRANK CASE ASS`Y
- DRIVE SHAFT HOUSING
- GEAR CASE (DRIVE SHAFT)
- GEAR CASE (PROPELLER SHAFT)
- HANDLE THROTTLE
- INTEGRAL FUEL TANK
- MAGNETO
- MOTOR COVER
- OPTIONAL PARTS ACCESSORIE (REMOTE CONTROL)
- OPTIONAL PARTS (ACCESSORIES)
- OPTIONAL PARTS ACCESSORIES (REMOTE CONTROL)
- PISTON CRANK SHAFT
- RECOIL STARTER STARTER LOCK
- SHIFT
