BOTTOM COWL для Tohatsu M40C - 2012 года выпуска
-
№АртикулНазвание
-
1345Q67100-2 BOTTOM COWL
Motor CoverBOTTOM COWL
Motor Cover -
2345-67113-0 MOUNT 12-18-2.5MOUNT 12-18-2.5
-
3345-67114-0 SPACER 8.4-12-17SPACER 8.4-12-17
-
49101E3-6835 BOLTBOLT
-
5345-67115-0 WASHER 6.5-21-1WASHER 6.5-21-1
-
6345-67151-0 CHOKE RODCHOKE ROD
-
7345-67193-0 GROMMET 16-2.5GROMMET 16-2.5
-
8338Q67141-0 HOOK LEVERHOOK LEVER
-
9338-67147-0 SEAL RINGSEAL RING
-
10350-67105-0 HOOK LEVER BUSHING 14-16.5-17.7HOOK LEVER BUSHING 14-16.5-17.7
-
113C8-67146-0 WASHER 14-22-1WASHER 14-22-1
-
12941403-1400 WAVE WASHER d=14WAVE WASHER d=14
-
13345-67142-1 COVER HOOKCOVER HOOK
-
14910103-6612 BOLTBOLT
-
153C8-66308-0 WASHER 6-16-1.5WASHER 6-16-1.5
-
16353-67162-0 GROMMETGROMMET
-
17345-83732-0 GROMMETGROMMET
-
18369-61016-0 GROMMET 29-3GROMMET 29-3
-
19345-67161-0 GROMMET 22-3
for EF/EP TypeGROMMET 22-3
for EF/EP Type -
20345-67161-0 GROMMET 22-3
for MF TypeGROMMET 22-3
for MF Type -
21345-67117-0 GROMMET 17-2.7
for EP TypeGROMMET 17-2.7
for EP Type -
22345-67183-0 AIR INTAKE BAFFLEAIR INTAKE BAFFLE
-
239101F4-0625 BOLTBOLT
-
24940103-0600 WASHERWASHER
-
25398-06830-0 STOP SWITCH ASSYSTOP SWITCH ASSY
-
26353-06821-0 * STOP SWITCH LANYARD ASSY* STOP SWITCH LANYARD ASSY
-
27336-06973-0 CLAMP 6-9.5LCLAMP 6-9.5L
-
28921503-5612 SCREWSCREW
-
29345-76081-0 NEUTRAL SWITCH BRACKET
for EF/EP TypeNEUTRAL SWITCH BRACKET
for EF/EP Type -
30910903-6616 BOLT
for EF/EP TypeBOLT
for EF/EP Type -
31910103-0612 BOLTBOLT
-
32345-66226-0 GROMMET 17-3GROMMET 17-3
-
33348-63061-0 THROTTLE SHAFT
for MF/EF TypeTHROTTLE SHAFT
for MF/EF Type -
34345-63063-0 THROTTLE SHAFT SUPPORT
for MF/EF TypeTHROTTLE SHAFT SUPPORT
for MF/EF Type -
359101F4-0630 BOLT
for MF/EF TypeBOLT
for MF/EF Type -
36940103-0600 WASHER
for MF/EF TypeWASHER
for MF/EF Type -
373B2-70260-1 FUEL CONNECTOR (MALE)FUEL CONNECTOR (MALE)
-
38332-70261-0 NUT 10-P1.25NUT 10-P1.25
-
39336-70112-0 GASKET 10.2-16-0.5GASKET 10.2-16-0.5
-
40361-72026-0 SPARK PLUG DECAL
BR7HS10SPARK PLUG DECAL
BR7HS10
Все узлы модели:
- CYLINDER CRANK CASE
- PISTON CRANK SHAFT
- INTAKE MAINFOLD FUEL PUMP
- CARBURETOR
- RECOIL STARTER
- MAGNETO
- ELECTRIC PARTS
- DRIVE SHAFT HOUSING
- GEAR CASE
- BRACKET
- TILLER HANDLE
- • BOTTOM COWL
- SHIFT
- REMOTE CONTROL PARTS
- TOP COWL
- FUEL TANK
- COMPONENT PARTS OF REMOTE CONTROL (ELECTRIC PARTS)
- COMPONENT PARTS OF REMOTE CONTROL
- OPTIONAL PARTS ACCESSORIES (1)
- OPTIONAL PARTS ACCESSORIES (2)
- ASSEMBLY KIT PARTS
