MAGNETO для Tohatsu 25JET - 2015 года выпуска
-
№АртикулНазвание
-
1345-01401-0 MAGNETO BASEMENTMAGNETO BASEMENT
-
2126-00121-0 OIL SEALOIL SEAL
-
3338-01403-0 O-RINGO-RING
-
4910121-6620 BOLTBOLT
-
53P0-06091-1 FLYWHEEL W/GEAR
FP 5531FLYWHEEL W/GEAR
FP 5531 -
63P0-06002-1 COIL PLATE ASSY W/ALTERNATOR
for M25/30H & 25JETCOIL PLATE ASSY W/ALTERNATOR
for M25/30H & 25JET -
83P0-06023-0 * ALTERNATOR ASSY
for M25/30H & 25JET* ALTERNATOR ASSY
for M25/30H & 25JET -
9921521-6528 * SCREW
for M25/30H & 25JET* SCREW
for M25/30H & 25JET -
103G3-06021-1 * EXCITER COIL
ALL* EXCITER COIL
ALL -
11921521-6525 * SCREW
ALL* SCREW
ALL -
12350-06025-0 * HOLDER
ALL* HOLDER
ALL -
133G2-06025-1 * HOLDER
for M25/30H & 25JET* HOLDER
for M25/30H & 25JET -
14921521-6406 * SCREW
for M25/30H & 25JET* SCREW
for M25/30H & 25JET -
163A3-76037-0 CABLE TERMINAL PLUG
for M25/30H & 25JETCABLE TERMINAL PLUG
for M25/30H & 25JET -
17353-76037-0 CABLE TERMINAL PLUG
for M25/30H & 25JETCABLE TERMINAL PLUG
for M25/30H & 25JET -
18346-63722-2 GUIDE PLATEGUIDE PLATE
-
19353-63723-1 SETTING RINGSETTING RING
-
20921521-6510 SCREW
for M25/30H & 25JETSCREW
for M25/30H & 25JET -
21346-05228-1 BALL JOINTBALL JOINT
-
223P0-06060-0 CD UNIT
CU 2561CD UNIT
CU 2561 -
23910103-6620 BOLTBOLT
-
243C8-66308-0 WASHERWASHER
-
25930103-0600 NUTNUT
-
263A0-06048-1 IGNITION COIL ASSY W/LABEL
IG 7302 for M25/30H & 25JETIGNITION COIL ASSY W/LABEL
IG 7302 for M25/30H & 25JET -
30346-06999-0 * PLUG CAP W/RESISTANCE
for M25/30H & 25JET* PLUG CAP W/RESISTANCE
for M25/30H & 25JET -
313Y9-06157-0 * PROTECTOR
#1* PROTECTOR
#1 -
323P0-06157-0 * PROTECTOR
#2* PROTECTOR
#2 -
333C8-72181-0 * CAUTION DECAL (B)* CAUTION DECAL (B)
-
34910103-5625 BOLTBOLT
-
35941303-0600 SPRING WASHERSPRING WASHER
-
36930103-0600 NUTNUT
-
373A0-06322-1 PLATEPLATE
-
38910103-6625 BOLTBOLT
-
393C8-66308-0 WASHERWASHER
-
403T4-06972-1 CLAMPCLAMP
-
413B7-06305-0 RUBBER MOUNTRUBBER MOUNT
-
423A0-76079-0 COLLARCOLLAR
-
433F3-06920-0 RUBBER MOUNTRUBBER MOUNT
-
44921503-5510 SCREWSCREW
-
453P0-06915-0 CLAMPCLAMP
-
46336-76091-0 LEAD WIRE BANDLEAD WIRE BAND
-
47334-00131-0 KEY
MagnetoKEY
Magneto -
48931121-1600 NUTNUT
-
49334-00133-0 WASHERWASHER
-
503C7-76142-1 GROUND CABLE
for MF Bottom Cowl -Electric PlateGROUND CABLE
for MF Bottom Cowl -Electric Plate -
51910103-0612 BOLTBOLT
-
523C7-06921-0 PLUG CAP W/RESISTANCE
OPTPLUG CAP W/RESISTANCE
OPT
