SHIFT для Tohatsu 25JET - 2015 года выпуска
-
№АртикулНазвание
-
13FG-64293-0 PLATE
25JETPLATE
25JET -
29101E3-5616 BOLT
25JETBOLT
25JET -
33EF-66211-0 SHIFT ROD
25JETSHIFT ROD
25JET -
43EF-76076-0 LINK ROD
25JETLINK ROD
25JET -
53EG-76076-0 LINK ROD
25JETLINK ROD
25JET -
63EF-61114-0 NUT
25JETNUT
25JET -
7930103-0600 NUT
25JETNUT
25JET -
83EF-66336-0 SPRING
25JETSPRING
25JET -
9940103-0600 WASHER
25JETWASHER
25JET -
103EF-65307-0 SNAP PIN
25JETSNAP PIN
25JET -
133FGQ66110-2 SHIFT LEVER
25JETSHIFT LEVER
25JET -
14346-66138-0 SPACERSPACER
-
15345-66137-0 OIL SEALOIL SEAL
-
16346-66121-0 SHIFT LEVER STOPPERSHIFT LEVER STOPPER
-
17910903-6512 BOLTBOLT
-
18345-66115-0 SHIFT LEVER STOP HOLDERSHIFT LEVER STOP HOLDER
-
19965002-1605 BALLBALL
-
20332-66112-0 SPRINGSPRING
-
219101F4-0616 BOLT
for M25/30H & JETBOLT
for M25/30H & JET -
22940103-0600 WASHER
for MF/EFWASHER
for MF/EF -
23346-67101-0 BUSHINGBUSHING
-
26345-66119-0 SHIM t=0.2SHIM t=0.2
Все узлы модели:
- CYLINDER CRANK CASE
- PISTON CRANK SHAFT
- INTAKE MAINFOLD FUEL PUMP
- CARBURETOR
- RECOIL STARTER
- MAGNETO
- DRIVE SHAFT HOUSING
- GEAR CASE (DRIVE SHAFT)
- JET DRIVE
- BRACKET
- TILLER HANDLE
- BOTTOM COWL
- • SHIFT
- TOP COWL
- FUEL TANK
- COMPONENT PARTS OF REMOTE CONTROL
- COMPONENT PARTS OF REMOTE CONTROL (ELECTRIC PARTS)
- OPTIONAL PARTS (ACCESSORIES) (1)
- ASSEMBLY KIT PARTS
