ELECTRICAL для Yamaha KODIAK 2WD YFM400AM (5HA1) - 2000 года выпуска
-
№АртикулНазвание
-
15GH-85540-00-00 C.D.I. UNIT ASSY (EXCPT CALIF)C.D.I. UNIT ASSY (EXCPT CALIF)
-
15GH-85540-10-00 C.D.I. UNIT ASSY (CALIF ONLY)C.D.I. UNIT ASSY (CALIF ONLY)
-
297707-60525-00 SCREW, TAPPINGSCREW, TAPPING
-
390462-06016-00 CLAMPCLAMP
-
490338-08226-00 PLUGPLUG
-
53GB-82540-01-00 NEUTRAL SWITCH ASSYNEUTRAL SWITCH ASSY
-
64KM-82540-00-00 NEUTRAL SWITCH ASSYNEUTRAL SWITCH ASSY
-
790430-10148-00 GASKETGASKET
-
83KJ-82310-10-00 IGNITION COIL ASSYIGNITION COIL ASSY
-
990109-06723-00 BOLTBOLT
-
1097007-06020-00 BOLTBOLT
-
1192907-06600-00 WASHER, PLATEWASHER, PLATE
-
121UY-82370-20-00 PLUG CAP ASSYPLUG CAP ASSY
-
134BA-82560-00-00 THERMO SWITCH ASSYTHERMO SWITCH ASSY
-
145GH-82560-00-00 THERMO SWITCH ASSYTHERMO SWITCH ASSY
-
154XV-83755-00-00 SENSOR, SPEEDSENSOR, SPEED
-
1690110-06001-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
175GT-81960-00-00 RECTIFIER & REGULATOR ASSYRECTIFIER & REGULATOR ASSY
-
1895807-06020-00 BOLT, FLANGEBOLT, FLANGE
-
194SH-82100-21-00 BATTERY ASSY (YTX20L-BS)BATTERY ASSY (YTX20L-BS)
-
205GH-82128-00-00 BRACKET, BATTERYBRACKET, BATTERY
-
21371-82121-00-00 PAD, BATTERYPAD, BATTERY
-
225GH-82119-00-00 COVER, LEAD WIRECOVER, LEAD WIRE
-
235GH-82129-00-00 COVER, BATTERYCOVER, BATTERY
-
2497707-50016-00 SCREW, TAPPINGSCREW, TAPPING
-
255GH-82115-00-00 WIRE, PLUS LEADWIRE, PLUS LEAD
-
265GH-82116-00-00 WIRE, MINUS LEADWIRE, MINUS LEAD
-
275GH-82541-00-00 WIRE, LEADWIRE, LEAD
-
284SV-81940-00-00 STARTER RELAY ASSYSTARTER RELAY ASSY
-
2995027-06008-00 BOLT, FLANGEBOLT, FLANGE
-
304GB-82510-10-00 MAIN SWITCH ASSYMAIN SWITCH ASSY
-
313HN-82579-00-00 ...CAP, KEY...CAP, KEY
-
325GH-83530-00-00 PILOT LIGHT ASSYPILOT LIGHT ASSY
-
335GH-83516-00-00 ...BULB (14V-1.7W)...BULB (14V-1.7W)
-
345HA-83530-00-00 PILOT LIGHT ASSYPILOT LIGHT ASSY
-
355GH-83516-00-00 ...BULB (14V-1.7W)...BULB (14V-1.7W)
-
365HA-82590-00-00 WIRE HARNESS ASSYWIRE HARNESS ASSY
-
373WP-81980-00-00 ...DIODE ASSY...DIODE ASSY
-
385GT-82180-00-00 ...CIRCUIT BREAKER ASSY...CIRCUIT BREAKER ASSY
-
395GT-82560-00-00 ......THERMO SWITCH ASSY......THERMO SWITCH ASSY
-
405HA-82309-00-00 WIRE, SUB LEADWIRE, SUB LEAD
-
415GH-82509-00-00 WIRE, SUB LEADWIRE, SUB LEAD
-
4229U-81950-93-00 RELAY ASSYRELAY ASSY
-
432NL-81950-92-00 RELAY ASSYRELAY ASSY
-
4490464-15195-00 CLAMPCLAMP
-
4590464-12089-00 CLAMPCLAMP
-
4690464-13073-00 CLAMPCLAMP
-
47437-83936-01-00 BAND, SWITCH CORDBAND, SWITCH CORD
-
4890464-13073-00 CLAMPCLAMP
-
4990464-13073-00 CLAMPCLAMP
-
5090464-13073-00 CLAMPCLAMP
-
5190464-12089-00 CLAMPCLAMP
-
5290464-12036-00 CLAMPCLAMP
-
5390464-10112-00 CLAMPCLAMP
-
545GH-8254B-00-00 TERMINAL COMP.TERMINAL COMP.
-
555GH-82114-00-00 NUTNUT
-
5690464-25098-00 CLAMPCLAMP
-
5790464-12089-00 CLAMPCLAMP
-
5890464-12089-00 CLAMPCLAMP
-
5990465-10098-00 CLAMPCLAMP
-
6090464-13073-00 CLAMPCLAMP
-
6190464-12089-00 CLAMPCLAMP
-
6290464-15195-00 CLAMPCLAMP
-
6390464-12089-00 CLAMPCLAMP
-
6490464-15195-00 CLAMPCLAMP
-
6590464-12089-00 CLAMPCLAMP
