SHIFT SHAFT для Yamaha RAPTOR 50 - 2007 года выпуска
-
№АртикулНазвание
-
15YF-18101-00-00 SHIFT SHAFT ASSYSHIFT SHAFT ASSY
-
290506-08122-00 ...SPRING, TENSION...SPRING, TENSION
-
390508-32563-00 ...SPRING, TORSION...SPRING, TORSION
-
4278-18127-01-00 STOPPER, SCREWSTOPPER, SCREW
-
593102-12106-00 OIL SEAL (SD 12-22-5 HS)OIL SEAL (SD 12-22-5 HS)
-
65YF-18121-10-00 LEVER, SHIFT 1LEVER, SHIFT 1
-
75YF-18174-00-00 KNOB, SHIFT LEVERKNOB, SHIFT LEVER
-
897022-06020-00 BOLTBOLT
-
990201-127F4-00 WASHER, PLATEWASHER, PLATE
-
1099009-12400-00 CIRCLIPCIRCLIP
