SEAT для Yamaha RAPTOR 700R SE - 2009 года выпуска
-
№АртикулНазвание
-
11S3-24710-61-00 SINGLE SEAT ASSYSINGLE SEAT ASSY
-
21S3-24731-60-00 COVER, SEATCOVER, SEAT
-
3371-27114-00-00 STOPPER, MAIN STANDSTOPPER, MAIN STAND
-
422W-24741-00-00 PAD, SEATPAD, SEAT
-
5509-24724-00-00 DAMPER, SEATDAMPER, SEAT
-
61S3-24723-00-00 DAMPER, SEATDAMPER, SEAT
