FUEL TANK для Yamaha FZS 1000 FZ1 CALIFORNIA - 2001 года выпуска
-
№АртикулНазвание
-
15LV-Y2410-10-01 FUEL TANK COMP. (OPT) (BLACK (BL2))FUEL TANK COMP. (OPT) (BLACK (BL2))
-
15LV-Y2410-10-04 FUEL TANK COMP. (OPT) (DEEP PURPLISH BLUE METALLIC (DPBMC))FUEL TANK COMP. (OPT) (DEEP PURPLISH BLUE METALLIC (DPBMC))
-
299226-00160-00 ......EMBLEM, YAMAHA (OPT) (BLACK (BL2))......EMBLEM, YAMAHA (OPT) (BLACK (BL2))
-
25DM-2153A-00-00 ......EMBLEM, YAMAHA (OPT) (DEEP PURPLISH BLUE METALLIC (DPBMC))......EMBLEM, YAMAHA (OPT) (DEEP PURPLISH BLUE METALLIC (DPBMC))
-
35LV-24191-00-00 BRACKET, FUEL TANK 1BRACKET, FUEL TANK 1
-
45LV-24181-10-00 DAMPER, LOCATING 1DAMPER, LOCATING 1
-
55LV-24183-10-00 DAMPER, LOCATING 3DAMPER, LOCATING 3
-
62GH-24186-00-00 WASHER, SPECIALWASHER, SPECIAL
-
797017-06030-00 BOLT, HEXAGONBOLT, HEXAGON
-
897027-06030-00 BOLTBOLT
-
992907-06600-00 WASHER, PLATEWASHER, PLATE
-
1090149-06298-00 SCREWSCREW
-
114YR-24181-00-00 DAMPER, LOCATING 1DAMPER, LOCATING 1
-
1290387-061W9-00 COLLARCOLLAR
-
1391317-06110-00 BOLT, SOCKETBOLT, SOCKET
-
145DM-21346-00-00 BRACKET, TANK FITTINGBRACKET, TANK FITTING
-
155LV-21346-00-00 BRACKET, TANK FITTINGBRACKET, TANK FITTING
-
165LV-24181-00-00 DAMPER, LOCATING 1DAMPER, LOCATING 1
-
175DM-24181-00-00 DAMPER, LOCATING 1DAMPER, LOCATING 1
-
1890387-06299-00 COLLARCOLLAR
-
1995807-06025-00 BOLT, FLANGEBOLT, FLANGE
-
205DM-21296-00-00 NUTNUT
-
2195817-06010-00 BOLT, FLANGEBOLT, FLANGE
-
222VN-24500-01-00 FUEL COCK ASSY. 1FUEL COCK ASSY. 1
-
234X8-24512-00-00 ......O-RING......O-RING
-
243AJ-24534-00-00 ......SEAL, COCK......SEAL, COCK
-
2598580-03008-00 ...SCREW, PAN HEAD...SCREW, PAN HEAD
-
2690149-06011-00 SCREWSCREW
-
2790202-05187-00 WASHER, PLATEWASHER, PLATE
-
285LV-24311-00-00 PIPE, FUEL 1PIPE, FUEL 1
-
2990467-12124-00 CLIPCLIP
-
305LV-24312-00-00 PIPE 2PIPE 2
-
311FK-24560-10-00 FILTER ASSY.FILTER ASSY.
-
325LV-24398-00-00 BAND 1BAND 1
-
335JJ-24602-00-00 CAP ASSY.CAP ASSY.
-
3490110-05112-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
3591317-05010-00 BOLTBOLT
-
364SV-13907-01-00 FUEL PUMP COMP.FUEL PUMP COMP.
-
3790464-44109-00 CLAMPCLAMP
-
385LV-13971-00-00 PIPE, FUEL 1PIPE, FUEL 1
-
3990467-13114-00 CLIP, SCISSORCLIP, SCISSOR
-
4090467-12124-00 CLIPCLIP
-
415LV-24182-00-00 DAMPER, LOCATING 2DAMPER, LOCATING 2
-
425LV-24183-00-00 DAMPER, LOCATING 3DAMPER, LOCATING 3
-
431UA-82591-00-00 BANDBAND
-
4490445-10021-00 HOSEHOSE
-
4490445-10021-00 HOSE (EXCEPT CALIF.)HOSE (EXCEPT CALIF.)
-
4590445-11025-00 HOSE (CALIF. ONLY)HOSE (CALIF. ONLY)
-
4690467-09006-00 CLIP (EXCEPT CALIF.)CLIP (EXCEPT CALIF.)
-
4790467-10008-00 CLIP (CALIF. ONLY)CLIP (CALIF. ONLY)
-
4790467-09006-00 CLIP (CALIF. ONLY)CLIP (CALIF. ONLY)
-
4890464-10075-00 CLAMPCLAMP
-
495LV-24180-00-00 ROLL OVER VALVE ASSY. (CALIF. ONLY)ROLL OVER VALVE ASSY. (CALIF. ONLY)
-
505LV-2411F-00-00 PLATE, FITTING 1 (CALIF. ONLY)PLATE, FITTING 1 (CALIF. ONLY)
-
5197007-05012-00 BOLT (CALIF. ONLY)BOLT (CALIF. ONLY)
-
5292907-05600-00 WASHER, PLATE (CALIF. ONLY)WASHER, PLATE (CALIF. ONLY)
-
535LV-24314-00-00 PIPE 4 (CALIF. ONLY)PIPE 4 (CALIF. ONLY)
-
545LV-24170-00-00 CANISTER ASSY (CALIF. ONLY)CANISTER ASSY (CALIF. ONLY)
-
5590464-15192-00 CLAMP (CALIF. ONLY)CLAMP (CALIF. ONLY)
-
5690480-13163-00 GROMMET (CALIF. ONLY)GROMMET (CALIF. ONLY)
-
5790387-062L2-00 COLLAR (CALIF. ONLY)COLLAR (CALIF. ONLY)
-
5895817-06016-00 BOLT, FLANGE (CALIF. ONLY)BOLT, FLANGE (CALIF. ONLY)
-
5990480-10068-00 GROMMET (CALIF. ONLY)GROMMET (CALIF. ONLY)
-
6090445-12003-00 HOSE (CALIF. ONLY)HOSE (CALIF. ONLY)
-
6190467-12052-00 CLIP, SCISSOR (CALIF. ONLY)CLIP, SCISSOR (CALIF. ONLY)
