CYLINDER для Yamaha YZF-R1 - 2003 года выпуска
-
№АртикулНазвание
-
15PW-11101-01-00 CYLINDER HEAD ASSYCYLINDER HEAD ASSY
-
23TJ-11133-10-00 ...GUIDE, VALVE...GUIDE, VALVE
-
31WG-11133-11-00 ...GUIDE, VALVE...GUIDE, VALVE
-
493440-07149-00 ...CIRCLIP...CIRCLIP
-
593440-10153-00 ...CIRCLIP...CIRCLIP
-
690340-27001-00 ...PLUG, STRAIGHT SCREW...PLUG, STRAIGHT SCREW
-
791808-16023-00 ...PIN, DOWEL...PIN, DOWEL
-
890105-06026-00 ...BOLT, FLANGE...BOLT, FLANGE
-
995617-08625-00 BOLT, STUDBOLT, STUD
-
1094701-00407-00 PLUG, SPARK (ND IU27D) (OPT)PLUG, SPARK (ND IU27D) (OPT)
-
1094701-00408-00 PLUG, SPARK (NGK IR CR9EIA 9) (OPT)PLUG, SPARK (NGK IR CR9EIA 9) (OPT)
-
1190201-10013-00 WASHER, PLATEWASHER, PLATE
-
1290176-10075-00 NUT, CROWNNUT, CROWN
-
1390179-10006-00 NUTNUT
-
1490179-10414-00 NUTNUT
-
1595024-06012-00 BOLT, FLG.(SMALL HEAD)BOLT, FLG.(SMALL HEAD)
-
1690430-06014-00 GASKETGASKET
-
175PW-11191-00-00 COVER, CYLINDER HEAD 1COVER, CYLINDER HEAD 1
-
185PW-11193-00-00 GASKET, HEAD COVER 1GASKET, HEAD COVER 1
-
1990109-066F0-00 BOLTBOLT
-
204KG-1111G-00-00 RUBBER, MOUNT 1RUBBER, MOUNT 1
-
215PW-11181-00-00 GASKET, CYLINDER HEAD 1GASKET, CYLINDER HEAD 1
-
2291317-06060-00 BOLTBOLT
-
235PW-11119-00-00 HANGER, ENGINEHANGER, ENGINE
-
2490149-06020-00 SCREWSCREW
