SIDE COVER для Yamaha V STAR CLASSIC - 2005 года выпуска
-
№АртикулНазвание
-
14TR-2160A-00-00 BOX COMP.BOX COMP.
-
290119-06118-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
34TR-2177G-02-00 BOX, BATTERY (EXCEPT CALIF.)BOX, BATTERY (EXCEPT CALIF.)
-
34TR-2177G-10-00 BOX, BATTERY (CALIF. ONLY)BOX, BATTERY (CALIF. ONLY)
-
45SC-2172K-00-00 BRACKET 1BRACKET 1
-
590267-32018-00 RIVET, BLINDRIVET, BLIND
-
622F-2139X-00-00 DAMPERDAMPER
-
75Y1-82122-00-00 SEAT, BATTERYSEAT, BATTERY
-
890446-14359-00 HOSEHOSE
-
990183-06053-00 NUT, SPRINGNUT, SPRING
-
1090119-06118-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
1190183-06023-00 NUT, SPRINGNUT, SPRING
-
1290119-06097-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
135BN-21711-10-PE COVER, SIDE 1 (SMX)COVER, SIDE 1 (SMX)
-
135BN-21711-10-PF COVER, SIDE 1 (S3 FOR DRMK)COVER, SIDE 1 (S3 FOR DRMK)
-
135BN-21711-10-PG COVER, SIDE 1 (DBNM8)COVER, SIDE 1 (DBNM8)
-
143LS-21781-10-00 EMBLEM,1EMBLEM,1
-
154TR-21717-00-00 DAMPERDAMPER
-
1690480-12320-00 GROMMETGROMMET
-
1755K-21708-00-00 LOCK ASSY. 2LOCK ASSY. 2
-
1890170-22187-00 NUTNUT
-
1990480-24186-00 GROMMETGROMMET
-
205BN-21721-00-PE COVER, SIDE 2 (SMX)COVER, SIDE 2 (SMX)
-
205BN-21721-00-PF COVER, SIDE 2 (S3 FOR DRMK)COVER, SIDE 2 (S3 FOR DRMK)
-
205BN-21721-00-PG COVER, SIDE 2 (DBNM8)COVER, SIDE 2 (DBNM8)
-
2184M-77555-00-00 PROTECTOR 5PROTECTOR 5
-
223LS-21781-10-00 EMBLEM,1EMBLEM,1
-
2390480-01559-00 GROMMETGROMMET
-
2490480-12320-00 GROMMETGROMMET
-
2590149-06302-00 SCREWSCREW
-
265BN-21731-00-00 COVER, SIDE 3COVER, SIDE 3
-
2790110-06254-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
2890480-10289-00 GROMMETGROMMET
-
2990387-0600V-00 COLLARCOLLAR
-
3091314-06020-00 BOLTBOLT
-
3190201-06062-00 WASHER, PLATEWASHER, PLATE
-
324VR-21741-00-00 COVER, SIDE 4COVER, SIDE 4
-
3390110-06200-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
344TR-28100-00-00 TOOL KITTOOL KIT
