COWLING для Yamaha FZ6 - 2008 года выпуска
-
№АртикулНазвание
-
14S8-28381-10-00 WINDSHIELDWINDSHIELD
-
290150-05023-00 SCREW, ROUND HEADSCREW, ROUND HEAD
-
390179-05523-00 NUT, SPEC'L SHAPENUT, SPEC'L SHAPE
-
44S8-Y283G-J0-P0 BODY, FRONT UPPER 1 FOR SMXBODY, FRONT UPPER 1 FOR SMX
-
44S8-Y283G-K0-P4 BODY, FRONT UPPER 1 FOR DPBMUBODY, FRONT UPPER 1 FOR DPBMU
-
590464-09009-00 ...CLAMP...CLAMP
-
690183-05076-00 ...NUT, SPRING...NUT, SPRING
-
790464-20003-00 ...CLAMP...CLAMP
-
84S8-28345-00-P3 ...MOLE 1 (MAT BLACK 2)...MOLE 1 (MAT BLACK 2)
-
997707-50016-00 ...SCREW, TRUSS HEAD TAPPING...SCREW, TRUSS HEAD TAPPING
-
104S8-28346-00-P3 ...MOLE 2 (MAT BLACK 2)...MOLE 2 (MAT BLACK 2)
-
114S8-283B1-C0-00 ...GRAPHIC SET FOR SMX...GRAPHIC SET FOR SMX
-
114S8-283B1-D0-00 ...GRAPHIC SET FOR DPBMU...GRAPHIC SET FOR DPBMU
-
124S8-28347-00-00 MOLE 3MOLE 3
-
134S8-28376-00-00 TRIMTRIM
-
144S8-28356-00-00 STAY 1STAY 1
-
153C3-83513-00-00 DAMPERDAMPER
-
1690480-14229-00 GROMMETGROMMET
-
1790119-08081-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
1890110-06200-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
1990202-06170-00 WASHER, PLATEWASHER, PLATE
-
204S8-2836K-00-00 PANEL, INNER 1PANEL, INNER 1
-
2190110-05201-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
224S8-2836L-00-00 PANEL, INNER 2PANEL, INNER 2
-
2390183-06053-00 NUT, SPRING (4ES)NUT, SPRING (4ES)
-
244S8-2836M-00-00 PANEL, INNER 3PANEL, INNER 3
-
2590183-06053-00 NUT, SPRING (4ES)NUT, SPRING (4ES)
-
264S8-2836F-00-00 BRACKET 3BRACKET 3
-
271FK-2171M-00-00 MOLE, SIDE COVER 2MOLE, SIDE COVER 2
-
2890464-16006-00 CLAMPCLAMP
-
294S8-2836E-00-00 BRACKET 2BRACKET 2
-
304S8-26280-00-00 REAR VIEW MIRROR ASSY (LEFT)REAR VIEW MIRROR ASSY (LEFT)
-
314S8-26290-00-00 REAR VIEW MIRROR ASSY (RIGHT)REAR VIEW MIRROR ASSY (RIGHT)
-
3295707-06500-00 NUT, FLANGE (4MV)NUT, FLANGE (4MV)
-
335VY-26298-00-00 PLATE, MIRROR FITTING 1PLATE, MIRROR FITTING 1
-
3490387-06372-00 COLLARCOLLAR
-
355JW-2835Y-00-00 LABEL, CAUTIONLABEL, CAUTION
