CARBURETOR для Yamaha V STAR 650 MIDNIGHT CUSTOM [ XVS65YB/C] (5S16/5S17) - 2009 года выпуска
-
№АртикулНазвание
-
15SC-14900-20-00 CARBURETOR ASSY FOR YBCCARBURETOR ASSY FOR YBC
-
15SC-14906-20-00 CARBURETOR ASSY FOR YBCARBURETOR ASSY FOR YB
-
25SC-14901-20-00 CARBURETOR ASSY #1 (REAR)CARBURETOR ASSY #1 (REAR)
-
35SC-14902-20-00 CARBURETOR ASSY #2 (FRONT)CARBURETOR ASSY #2 (FRONT)
-
44TR-14103-00-00 THROTTLE SCREW SET #2 (FRONT)THROTTLE SCREW SET #2 (FRONT)
-
54TR-14105-00-00 PILOT SCREW SETPILOT SCREW SET
-
63F9-14118-00-00 CAPCAP
-
75BN-1490J-00-00 NEEDLE SETNEEDLE SET
-
84DN-1410A-01-00 STARTER SETSTARTER SET
-
93CF-14107-10-00 NEEDLE VALVE SETNEEDLE VALVE SET
-
101HX-14231-20-00 JET,PILOT AIR (#100)JET,PILOT AIR (#100)
-
114KM-14142-20-00 JET, PILOT (#20)JET, PILOT (#20)
-
123DM-1414M-34-00 NOZZLE, MAINNOZZLE, MAIN
-
133G2-1414E-36-00 JET, MAIN (#91.3)JET, MAIN (#91.3)
-
148F2-14147-00-00 O-RINGO-RING
-
154VR-14933-00-00 SPRING, DIAPHRAGMSPRING, DIAPHRAGM
-
165FU-83790-00-00 HEATER ASSY (15W)HEATER ASSY (15W)
-
175FU-83790-10-00 HEATER ASSY (20W)HEATER ASSY (20W)
-
1890201-08016-00 WASHER, PLATE #1 (REAR)WASHER, PLATE #1 (REAR)
-
1890201-08016-00 WASHER, PLATE #2 (FRONT)WASHER, PLATE #2 (FRONT)
-
194DH-82103-00-00 TERMINAL 1TERMINAL 1
-
201HX-14147-00-00 O-RINGO-RING
-
211AE-14227-00-00 O-RINGO-RING
-
225SC-14261-00-00 HOLDERHOLDER
-
231AE-14237-00-00 GASKETGASKET
-
241HX-14565-00-00 SCREWSCREW
-
25137-14153-00-00 WASHER, MAIN JETWASHER, MAIN JET
-
264TR-14940-00-00 DIAPHRAGM ASSYDIAPHRAGM ASSY
-
271UY-14565-00-00 SCREWSCREW
-
283KW-14486-00-00 SCREW, ROD #2 (FRONT)SCREW, ROD #2 (FRONT)
-
2922V-14940-00-00 DIAPHRAGM ASSYDIAPHRAGM ASSY
-
305SC-14275-00-00 SPRINGSPRING
-
314TR-14348-00-00 PIPE 1PIPE 1
-
3298507-04008-00 SCREW, PAN HEAD #2 (FRONT)SCREW, PAN HEAD #2 (FRONT)
-
3298507-04008-00 SCREW, PAN HEAD #1 (REAR)SCREW, PAN HEAD #1 (REAR)
-
3398707-04014-00 SCREW, FLAT HEAD #2 (FRONT)SCREW, FLAT HEAD #2 (FRONT)
-
3398707-04014-00 SCREW, FLAT HEAD #1 (REAR)SCREW, FLAT HEAD #1 (REAR)
-
344VR-24453-00-00 SCREW #2 (FRONT)SCREW #2 (FRONT)
-
355LW-14191-00-00 PLUG, DRAINPLUG, DRAIN
-
364TR-14937-00-00 CLIP #2 (FRONT)CLIP #2 (FRONT)
-
371FN-14565-00-00 SCREWSCREW
-
38353-14186-00-00 PIN, FLOATPIN, FLOAT
-
391HX-14985-00-00 FLOATFLOAT
-
405SC-1410H-10-00 FUEL CUT SOLENOID VALVE #1 (REAR)FUEL CUT SOLENOID VALVE #1 (REAR)
-
405SC-1410H-00-00 FUEL CUT SOLENOID VALVE #2 (FRONT)FUEL CUT SOLENOID VALVE #2 (FRONT)
-
41256-14956-01-00 WASHERWASHER
-
424HM-14239-00-00 SEALSEAL
-
434TR-1490L-00-00 STARTER LEVER SET, 1STARTER LEVER SET, 1
-
443KW-1490K-00-00 STOP SCREW SETSTOP SCREW SET
-
4536Y-14147-00-00 O-RINGO-RING
-
461WG-14251-00-00 NIPPLENIPPLE
-
474TR-14987-00-00 HOSEHOSE
-
484KM-24453-00-00 SCREWSCREW
-
494NK-85885-00-00 THROTTLE POSITION SENSOR ASSY.THROTTLE POSITION SENSOR ASSY.
-
505SC-81517-00-00 WIRE, SUB LEADWIRE, SUB LEAD
-
5135H-14139-00-00 CLIP, PIPECLIP, PIPE
-
5255X-14937-00-00 CLIPCLIP
-
535GK-1491A-00-00 CAPCAP
