HEADLIGHT для Yamaha V STAR 650 MIDNIGHT CUSTOM [ XVS65YB/C] (5S16/5S17) - 2009 года выпуска
-
№АртикулНазвание
-
15KP-84310-01-00 HEADLIGHT UNIT ASSYHEADLIGHT UNIT ASSY
-
25JX-84315-01-00 RIM, HEADLIGHTRIM, HEADLIGHT
-
35KP-84321-00-00 LENS ASSYLENS ASSY
-
45JX-84316-00-00 BRACKETBRACKET
-
52F9-84314-00-00 BULB (12V-60/55W)BULB (12V-60/55W)
-
64JG-84397-00-00 COVER, SOCKETCOVER, SOCKET
-
7341-84331-60-00 SCREW, PAN HEADSCREW, PAN HEAD
-
85G2-84332-60-00 SPRING, SCREWSPRING, SCREW
-
947J-84334-00-00 NUT, ADJUSTINGNUT, ADJUSTING
-
104KG-84365-00-00 SCREWSCREW
-
1150W-84333-00-00 COLLAR, SCREWCOLLAR, SCREW
-
1292902-06100-00 WASHER, SPRINGWASHER, SPRING
-
134KG-84334-00-00 NUT, ADJUSTINGNUT, ADJUSTING
-
145JX-84330-10-00 BODY ASSYBODY ASSY
-
1542X-84345-00-00 DAMPER, HEADLIGHTDAMPER, HEADLIGHT
-
161FK-84338-00-00 COLLAR, BODY FITTINGCOLLAR, BODY FITTING
-
175JX-84388-00-00 COLLAR 1COLLAR 1
-
1890157-05011-00 SCREW, PAN HEADSCREW, PAN HEAD
-
1992014-06045-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
2090176-06047-00 NUT, CROWNNUT, CROWN
-
2190464-12089-00 CLAMPCLAMP
