CARBURETOR для Yamaha V STAR 650 SILVERADO [ XVS65ATYB/R/CB/CR] (4C5V/4C5W) - 2009 года выпуска
-
№АртикулНазвание
-
15SC-14900-20-00 CARBURETOR ASSY (CALIF ONLY)CARBURETOR ASSY (CALIF ONLY)
-
15SC-14906-20-00 CARBURETOR ASSY (EXCEPT CALIF)CARBURETOR ASSY (EXCEPT CALIF)
-
25SC-14901-20-00 ...CARBURETOR ASSY 1 (#1) (REAR)...CARBURETOR ASSY 1 (#1) (REAR)
-
35SC-14902-20-00 ...CARBURETOR ASSY 2 (#2) (FRONT)...CARBURETOR ASSY 2 (#2) (FRONT)
-
44TR-14103-00-00 ......THROTTLE SCREW SET (#2) (FRONT)......THROTTLE SCREW SET (#2) (FRONT)
-
54TR-14105-00-00 ......PILOT SCREW SET......PILOT SCREW SET
-
63F9-14118-00-00 ......CAP......CAP
-
75BN-1490J-00-00 ......NEEDLE SET......NEEDLE SET
-
84DN-1410A-01-00 ......STARTER SET......STARTER SET
-
93CF-14107-10-00 ......NEEDLE VALVE SET......NEEDLE VALVE SET
-
101HX-14231-20-00 ......JET,PILOT AIR (#100)......JET,PILOT AIR (#100)
-
114KM-14142-20-00 ......JET, PILOT (#20)......JET, PILOT (#20)
-
123DM-1414M-34-00 ......NOZZLE, MAIN......NOZZLE, MAIN
-
133G2-1414E-36-00 ......JET, MAIN (#91.3)......JET, MAIN (#91.3)
-
148F2-14147-00-00 ......O-RING......O-RING
-
154VR-14933-00-00 ......SPRING, DIAPHRAGM......SPRING, DIAPHRAGM
-
165FU-83790-00-00 ......HEATER ASSY (15W)......HEATER ASSY (15W)
-
175FU-83790-10-00 ......HEATER ASSY (20W)......HEATER ASSY (20W)
-
1890201-08016-00 ......WASHER, PLATE (#2) (FRONT)......WASHER, PLATE (#2) (FRONT)
-
1890201-08016-00 ......WASHER, PLATE (#1) (REAR)......WASHER, PLATE (#1) (REAR)
-
194DH-82103-00-00 ......TERMINAL 1 (#1) (REAR)......TERMINAL 1 (#1) (REAR)
-
201HX-14147-00-00 ......O-RING......O-RING
-
211AE-14227-00-00 ......O-RING......O-RING
-
225SC-14261-00-00 ......HOLDER......HOLDER
-
231AE-14237-00-00 ......GASKET......GASKET
-
241HX-14565-00-00 ......SCREW......SCREW
-
25137-14153-00-00 ......WASHER,MAIN JET......WASHER,MAIN JET
-
264TR-14940-00-00 ......DIAPHRAGM ASSY......DIAPHRAGM ASSY
-
271UY-14565-00-00 ......SCREW......SCREW
-
283KW-14486-00-00 ......SCREW, ROD (#2) (FRONT)......SCREW, ROD (#2) (FRONT)
-
2922V-14940-00-00 ......DIAPHRAGM ASSY......DIAPHRAGM ASSY
-
305SC-14275-00-00 ......SPRING......SPRING
-
314TR-14348-00-00 ......PIPE 1......PIPE 1
-
3298507-04008-00 ......SCREW, PAN HEAD (#2) (FRONT)......SCREW, PAN HEAD (#2) (FRONT)
-
3298507-04008-00 ......SCREW, PAN HEAD (#1) (REAR)......SCREW, PAN HEAD (#1) (REAR)
-
3398502-04014-00 ............SCREW, PAN HEAD (#2) (FRONT)............SCREW, PAN HEAD (#2) (FRONT)
-
3398502-04014-00 ............SCREW, PAN HEAD (#1) (REAR)............SCREW, PAN HEAD (#1) (REAR)
-
344VR-24453-00-00 ......SCREW (#2) (FRONT)......SCREW (#2) (FRONT)
-
355LW-14191-00-00 ......PLUG, DRAIN......PLUG, DRAIN
-
364TR-14937-00-00 ......CLIP (#2) (FRONT)......CLIP (#2) (FRONT)
-
371FN-14565-00-00 ......SCREW......SCREW
-
38353-14186-00-00 ......PIN, FLOAT......PIN, FLOAT
-
391HX-14985-00-00 ......FLOAT......FLOAT
-
405SC-1410H-00-00 ......FUEL CUT SOLENOID VALVE (#2) (FRONT)......FUEL CUT SOLENOID VALVE (#2) (FRONT)
-
405SC-1410H-10-00 ......FUEL CUT SOLENOID VALVE (#1) (REAR)......FUEL CUT SOLENOID VALVE (#1) (REAR)
-
41256-14956-01-00 ......WASHER......WASHER
-
424HM-14239-00-00 ...SEAL...SEAL
-
434TR-1490L-00-00 ...STARTER LEVER SET, 1...STARTER LEVER SET, 1
-
443KW-1490K-00-00 ...STOP SCREW SET...STOP SCREW SET
-
4536Y-14147-00-00 ...O-RING...O-RING
-
461WG-14251-00-00 ...NIPPLE...NIPPLE
-
474TR-14987-00-00 ...HOSE...HOSE
-
484KM-24453-00-00 ...SCREW...SCREW
-
494NK-85885-00-00 ...THROTTLE POSITION SENSOR ASS...THROTTLE POSITION SENSOR ASS
-
505SC-81517-00-00 ...WIRE, SUB LEAD...WIRE, SUB LEAD
-
5135H-14139-00-00 ...CLIP, PIPE...CLIP, PIPE
-
5255X-14937-00-00 ...CLIP...CLIP
-
535GK-1491A-00-00 ...CAP...CAP
