DRIVE SHAFT для Yamaha FJR1300A ABS - 2010 года выпуска
-
№АртикулНазвание
-
13P6-W4612-30-00 REAR AXLE GEAR CASE ASSYREAR AXLE GEAR CASE ASSY
-
290116-10010-00 BOLT, STUDBOLT, STUD
-
390116-08025-00 BOLT, STUDBOLT, STUD
-
45JW-46153-00-00 COLLAR, GUIDECOLLAR, GUIDE
-
593101-30084-00 OIL SEALOIL SEAL
-
693311-43729-00 BEARINGBEARING
-
72H7-46102-00-00 BEARING ASSYBEARING ASSY
-
81J7-17537-Y0-40 SHIM, THRUST (0.40T)SHIM, THRUST (0.40T)
-
81J7-17537-Y0-50 SHIM, THRUST (0.50T)SHIM, THRUST (0.50T)
-
81J7-17537-Y0-30 SHIM, THRUST (0.30T)SHIM, THRUST (0.30T)
-
993306-30533-00 BEARINGBEARING
-
104H7-46125-00-00 RETAINER, BEARINGRETAINER, BEARING
-
1193210-60426-00 O-RINGO-RING
-
1293101-38001-00 OIL SEALOIL SEAL
-
133P6-46123-01-00 COUPLING, GEARCOUPLING, GEAR
-
1490201-166R5-00 WASHER, PLATEWASHER, PLATE
-
1590179-16010-00 NUTNUT
-
163P6-46152-00-00 HOUSING, BEARINGHOUSING, BEARING
-
171J7-46117-Y0-40 SHIM, RING GEAR (0.40T)SHIM, RING GEAR (0.40T)
-
171J7-46117-Y0-25 SHIM, RING GEAR (0.25T)SHIM, RING GEAR (0.25T)
-
171J7-46117-Y0-30 SHIM, RING GEAR (0.30T)SHIM, RING GEAR (0.30T)
-
171J7-46117-Y0-50 SHIM, RING GEAR (0.50T)SHIM, RING GEAR (0.50T)
-
1893316-01403-00 BEARINGBEARING
-
1922U-46118-00-20 SHIM, THRUST (2.0T)SHIM, THRUST (2.0T)
-
1922U-46118-00-18 SHIM, THRUST (1.8T)SHIM, THRUST (1.8T)
-
1922U-46118-00-16 SHIM, THRUST (1.6T)SHIM, THRUST (1.6T)
-
1922U-46118-00-14 SHIM, THRUST (1.4T)SHIM, THRUST (1.4T)
-
1922U-46118-00-12 SHIM, THRUST (1.2T)SHIM, THRUST (1.2T)
-
2093211-54698-00 O-RINGO-RING
-
2195312-08600-00 NUTNUT
-
2290204-08001-00 WASHER, SPRINGWASHER, SPRING
-
2395812-10050-00 BOLT, FLANGEBOLT, FLANGE
-
2493102-70167-00 OIL SEALOIL SEAL
-
2590340-14132-00 PLUG, STRAIGHT SCREWPLUG, STRAIGHT SCREW
-
26214-11198-01-00 GASKETGASKET
-
272H7-17590-00-00 BREATHER COMP.BREATHER COMP.
-
2890340-14004-00 PLUG, STRAIGHT SCREWPLUG, STRAIGHT SCREW
-
291FK-46154-00-00 COVER, HOUSINGCOVER, HOUSING
-
301FK-46156-00-00 STOPPER, RING GEARSTOPPER, RING GEAR
-
311FK-46157-00-15 SHIM, STOPPER (T=0.15)SHIM, STOPPER (T=0.15)
-
311FK-46157-00-20 SHIM, STOPPER (T=0.20)SHIM, STOPPER (T=0.20)
-
325VS-4615A-00-00 COLLAR, GUIDE 1COLLAR, GUIDE 1
-
333P6-46172-10-00 SHAFT, DRIVESHAFT, DRIVE
-
3493108-43001-00 OIL SEALOIL SEAL
-
3590201-23008-00 WASHER, PLATEWASHER, PLATE
-
3693410-23056-00 CIRCLIPCIRCLIP
-
3793410-22039-00 CIRCLIPCIRCLIP
-
385JW-46180-00-00 CROSS JOINT COMP.CROSS JOINT COMP.
-
3990501-16491-00 SPRING, COMPRESSIONSPRING, COMPRESSION
-
4090176-10075-00 NUT, CROWNNUT, CROWN
-
4192990-10600-00 WASHER, PLATEWASHER, PLATE
