STARTING MOTOR для Yamaha FX HO - 2009 года выпуска
-
№АртикулНазвание
-
16S5-81800-00-00 STARTING MOTOR ASSYSTARTING MOTOR ASSY
-
211H-81844-00-00 .GASKET.GASKET
-
36S5-81830-00-00 .FRONT BRACKET ASSY.FRONT BRACKET ASSY
-
44G0-81844-00-00 ..GASKET..GASKET
-
51J7-81847-60-00 ..O-RING..O-RING
-
65EL-15511-00-00 ..GEAR, STARTING MOTOR..GEAR, STARTING MOTOR
-
793410-12003-00 ..CIRCLIP..CIRCLIP
-
86S5-81840-00-00 .BRUSH HOLDER ASSY.BRUSH HOLDER ASSY
-
93TB-81847-00-00 ..O-RING..O-RING
-
106S5-81826-00-00 .BOLT.BOLT
-
115EL-81845-00-00 .PLATE.PLATE
-
126S5-81820-00-00 .REAR BRACKET ASSY.REAR BRACKET ASSY
-
136S5-81810-00-00 .STATOR ASSY.STATOR ASSY
-
145A8-81850-10-00 .ARMATURE ASSY.ARMATURE ASSY
-
1597013-08030-00 BOLTBOLT
-
1692903-08600-00 WASHER, PLATEWASHER, PLATE
-
1792990-06100-00 .WASHER, SPRING.WASHER, SPRING
-
1895380-06700-00 NUTNUT
