INTAKE AND RIDE PLATE ASSY для Yamaha FZS - 2009 года выпуска
-
№АртикулНазвание
-
16AN-R1333-01-00 SCREEN, INTAKESCREEN, INTAKE
-
26AN-R1341-00-00 BRACKET 1BRACKET 1
-
3F1S-U8K31-02-00 SENSOR SPEEDSENSOR SPEED
-
4EU0-62241-30-00 NUT, DRAIN 1NUT, DRAIN 1
-
590150-05807-00 SCREW, ROUND HEADSCREW, ROUND HEAD
-
690600-91736-00 CLAMP COMP.CLAMP COMP.
-
790267-48802-00 RIVET, BLINDRIVET, BLIND
-
890464-32801-00 CLAMPCLAMP
-
99299R-05200-00 WASHERWASHER
-
1090464-32801-00 CLAMPCLAMP
-
1190464-99801-00 CLAMPCLAMP
-
1290267-489U6-00 RIVET, BLINDRIVET, BLIND
-
13F1S-U725E-00-00 WASHERWASHER
-
1490201-10801-00 WASHER, PLATEWASHER, PLATE
-
159572R-10300-00 NUT, NYLONNUT, NYLON
-
1690600-91736-00 CLAMP COMP.CLAMP COMP.
-
1790464-32801-00 CLAMPCLAMP
-
1890267-48802-00 RIVET, BLINDRIVET, BLIND
-
19F2C-U273B-02-00 PLATE 2PLATE 2
-
20F2C-U143G-00-00 SPACERSPACER
-
2190119-08823-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
22F1G-U8572-01-00 BRACKET 2BRACKET 2
-
23F2C-U8577-02-00 BRACKET, 3BRACKET, 3
-
2490119-10808-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
25F2C-U7557-01-00 BRACKETBRACKET
-
2690119-089U7-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
2790430-12002-00 GASKETGASKET
-
2892990-12200-00 WASHER, PLAINWASHER, PLAIN
-
2990109-08041-00 BOLTBOLT
-
30F2C-U757E-01-00 PLATE, RUBBER 1PLATE, RUBBER 1
-
31F2C-U757F-01-00 PLATE, RUBBER 2PLATE, RUBBER 2
-
3290387-06080-00 COLLARCOLLAR
-
3390119-06827-00 BOLT, WITH WASHERBOLT, WITH WASHER
