INSTRUMENT PANEL для Yamaha VINO 125 - 2004 года выпуска
-
№АртикулНазвание
-
15YR-H3510-00-00 SPEEDOMETER ASSY.SPEEDOMETER ASSY.
-
25YR-H351A-00-00 ...METER ASSY....METER ASSY.
-
35FH-H357K-00-00 ...PACKING,METER...PACKING,METER
-
45YR-H3519-00-00 ...BRACKET, METER...BRACKET, METER
-
55FH-H3507-00-00 ...COVER, SPEEDOMETER...COVER, SPEEDOMETER
-
65FH-H3616-00-00 ...SCREW, TAPPING...SCREW, TAPPING
-
75YR-H3509-00-00 ...SOCKET CORD ASSY....SOCKET CORD ASSY.
-
85FH-H3517-00-00 ...BULB...BULB
-
93KW-H3517-00-00 ...BULB (12V 1.7W)...BULB (12V 1.7W)
-
1091317-06010-00 BOLTBOLT
-
115YR-H3550-00-00 SPEEDOMETER CABLE ASSY.SPEEDOMETER CABLE ASSY.
-
125YR-H3551-00-00 ...WIRE, SPEEDOMETER CABLE...WIRE, SPEEDOMETER CABLE
-
135FH-H5750-00-00 FUEL METER ASSY.FUEL METER ASSY.
-
145FH-H3517-00-00 ...BULB...BULB
-
1590176-06055-00 NUT, CROWNNUT, CROWN
