CRANKSHAFT W/ PISTON ASSY для Yamaha V-MAX 500 - 2000 года выпуска
-
№АртикулНазвание
-
18CJ-11631-00-A0 PISTON (STD)PISTON (STD)
-
28AB-11603-01-00 PISTON RING SET (STD)PISTON RING SET (STD)
-
38H8-11633-00-00 PIN, PISTONPIN, PISTON
-
493450-21053-00 CIRCLIPCIRCLIP
-
593310-320G0-00 BEARING, CYL.#10BEARING, CYL.#10
-
68CR-11400-02-00 CRANKSHAFT ASSEMBLYCRANKSHAFT ASSEMBLY
-
782M-11412-02-00 ...CRANK 1...CRANK 1
-
882M-11422-00-00 ...CRANK 2...CRANK 2
-
982M-11432-00-00 ...CRANK 3...CRANK 3
-
1082M-11442-00-00 ...CRANK 4...CRANK 4
-
1182M-11651-00-00 ...ROD, CONNECTING...ROD, CONNECTING
-
1282M-11681-00-00 ...PIN, CRANK 1...PIN, CRANK 1
-
1393310-525S1-00 ...BEARING...BEARING
-
1482M-11685-00-00 ...WASHER, CRANK PIN...WASHER, CRANK PIN
-
158R9-11685-00-00 ...WASHER, CRANK PIN...WASHER, CRANK PIN
-
1693399-99946-00 ...BEARING...BEARING
-
1793306-30720-00 ...BEARING...BEARING
-
1890201-357E4-00 ...WASHER, PLATE...WASHER, PLATE
-
1993306-20712-00 ...BEARING...BEARING
-
2082M-11515-00-00 ...SEAL, LABYRINTH 1...SEAL, LABYRINTH 1
-
2193399-99945-00 ...BEARING...BEARING
-
2293440-80023-00 ...CIRCLIP...CIRCLIP
-
238CR-11428-01-00 ...BEARING 1...BEARING 1
-
248CR-11429-00-00 ...BEARING 2...BEARING 2
-
2593103-35176-00 OIL SEAL, SW-TYPEOIL SEAL, SW-TYPE
-
2693103-32153-00 OIL SEAL, SW-TYPEOIL SEAL, SW-TYPE
-
2790280-05033-00 KEY, WOODRUFFKEY, WOODRUFF
-
2890170-16425-00 NUTNUT
-
2992907-16600-00 WASHERWASHER
