OIL PUMP ASSY для Yamaha VK 540 III - 2003 года выпуска
-
№АртикулНазвание
-
18AT-13101-00-00 OIL PUMP ASSYOIL PUMP ASSY
-
290338-21075-00 ...PLUG...PLUG
-
393505-32002-00 ...BALL...BALL
-
490501-02217-00 ...SPRING, COMPRESSION...SPRING, COMPRESSION
-
591A30-03042-00 ...TUBE, FLEXIBLE VINYL...TUBE, FLEXIBLE VINYL
-
6353-13552-01-00 ...NOZZLE...NOZZLE
-
790468-02025-00 ...CLIP...CLIP
-
890430-04004-00 ...GASKET...GASKET
-
998902-04020-00 ...SCREW, BIND...SCREW, BIND
-
10137-13138-01-00 ...PLATE, ADJUSTING...PLATE, ADJUSTING
-
11137-13137-00-00 ...SHIM, PLUNGER...SHIM, PLUNGER
-
1292901-05100-00 ...WASHER, SPRING...WASHER, SPRING
-
1395301-05600-00 ...NUT...NUT
-
1490201-08624-00 WASHER, PLATEWASHER, PLATE
-
1598507-05016-00 SCREWSCREW
-
1692907-05100-00 WASHER, SPRINGWASHER, SPRING
-
178Y0-13116-01-00 GASKET, PUMP CASEGASKET, PUMP CASE
-
1890468-02025-00 CLIPCLIP
-
198A5-13146-01-00 COVER,ADJUST PULLEYCOVER,ADJUST PULLEY
-
2098507-04018-00 SCREWSCREW
-
218L8-26320-04-00 PUMP CABLE ASSYPUMP CABLE ASSY
-
2290464-16039-00 CLAMPCLAMP
