COOLING SYSTEM для Yamaha PHAZER RTX - 2013 года выпуска
-
№АртикулНазвание
-
18GC-1243E-00-00 HOSE 2HOSE 2
-
290450-35001-00 HOSE CLAMP ASSYHOSE CLAMP ASSY
-
38GC-1244G-00-00 HOSE, 4HOSE, 4
-
490450-38040-00 HOSE CLAMP ASSYHOSE CLAMP ASSY
-
58GC-12580-00-00 JOINT ASSYJOINT ASSY
-
65VX-12413-00-00 ...COVER, THERMOSTAT...COVER, THERMOSTAT
-
78FN-12410-00-00 ...THERMOSTAT ASSY...THERMOSTAT ASSY
-
88EK-12412-00-00 ......SEAL, THERMOSTAT......SEAL, THERMOSTAT
-
995822-06020-00 ...BOLT, FLANGE...BOLT, FLANGE
-
108CC-85790-01-00 ...THERMOSENSOR ASSY...THERMOSENSOR ASSY
-
1190201-12790-00 ...WASHER, PLATE...WASHER, PLATE
-
128GC-1243F-00-00 HOSE, 3HOSE, 3
-
1390450-38040-00 HOSE CLAMP ASSYHOSE CLAMP ASSY
-
1490450-35001-00 HOSE CLAMP ASSYHOSE CLAMP ASSY
-
158GC-1249B-00-00 TANK, RESERVETANK, RESERVE
-
1690445-08022-00 HOSEHOSE
-
1722W-12462-00-00 CAP, RADIATORCAP, RADIATOR
-
1890387-06024-00 COLLARCOLLAR
-
1995822-06020-00 BOLT, FLANGEBOLT, FLANGE
-
208GC-12476-00-00 PIPE 6PIPE 6
-
218GC-12477-00-00 PIPE 7PIPE 7
-
2290450-35001-00 HOSE CLAMP ASSYHOSE CLAMP ASSY
-
238GC-12564-00-00 PIPE, WATERPIPE, WATER
-
248GC-12481-00-00 PIPE 1PIPE 1
-
258GC-12465-00-00 DAMPER, RADIATORDAMPER, RADIATOR
-
2616G-13569-00-00 PLUG, BLINDPLUG, BLIND
-
2790467-11028-00 CLIPCLIP
-
288GC-12461-00-00 RADIATOR COMPRADIATOR COMP
-
298GJ-12405-00-00 BLOWER ASSYBLOWER ASSY
-
305SL-12671-00-00 NUT 1NUT 1
-
315GJ-12675-00-00 BOLT, BLOWER HOLDINGBOLT, BLOWER HOLDING
-
3290480-15528-00 GROMMETGROMMET
-
3390387-06065-00 COLLARCOLLAR
-
3495022-06030-00 BOLT, FLANGEBOLT, FLANGE
-
3590201-06380-00 WASHER PLAINWASHER PLAIN
-
368GC-1248A-00-00 PIPE 8PIPE 8
-
3790450-35001-00 HOSE CLAMP ASSYHOSE CLAMP ASSY
Все узлы модели:
- BELT GUARD W/ TOOL BOX
- BRAKE ASSY
- BUMPER - FRONT AND REAR
- CAMSHAFT W/ CAMSHAFT CHAIN ASSY
- CHAINCASE - SPROCKET AND CHAINS (OPTION)
- CHAINCASE ASSY
- CLUTCH - DRIVE
- CLUTCH - DRIVEN W/ DRIVE AXLE
- CLUTCH - REPAIR KIT (OPTION)
- CLUTCH - TUNE-UP KIT (OPTION)
- CLUTCH - WEIGHTS AND SPRINGS (OPTION)
- CONSOLE ASSY
- • COOLING SYSTEM
- CRANKCASE ASSY
- CRANKCASE COVER ASSY
- CRANKSHAFT W/ PISTON ASSY
- CYLINDER W/ HEAD ASSY
- DECALS
- DRIVE TRAIN ASSEMBLY
- ELECTRICAL - BATTERY ASSY
- ELECTRICAL - COIL, CDI, RECTIFIER, RELAYS AND SWITCHES
- ELECTRICAL - HEADLIGHT ASSY
- ELECTRICAL - INSTRUMENTS
- ELECTRICAL - MAGNETO ASSEMBLY
- ELECTRICAL - TAILLIGHT ASSY
- ENGINE MOUNTING
- EXHAUST SYSTEM
- FUEL TANK ASSY
- HANDLEBAR - CABLES AND GRIPS
- HANDLEBAR - SWITCHES AND LEVERS
- HANDLEBAR ASSY W/ STEERING ASSY
- HANDLEBAR PAD W/ STEERING GATE
- HOOD - WINDSHIELD ASSY
- HOOD ASSY
- INTAKE W/ AIR BOX ASSY - FUEL PUMP
- MODEL INFO - COLOR CHART
- OIL COOLER ASSY W/ OIL FILTER
- OIL PUMP ASSY
- OIL TANK ASSY
- REAR VIEW MIRROR ASSY (OPTION)
- REFLECTOR ASSY
- SEAT ASSY
- STARTER - ELECTRICAL STARTER ASSY
- STARTER - REDUCTION GEAR W/ CLUTCH ASSY
- SUSPENSION - FRONT W/ SKI ASSY
- SUSPENSION - IDLER WHEELS W/ RAIL ASSY - TRACK
- SUSPENSION - IDLER WHEELS W/ RAIL ASSY - TRACK 2
- THROTTLE BODY ASSY
- TUNNEL ASSEMBLY W/ LOWER NOSEPAN
- VALVE ASSY
- WATER PUMP ASSY
