HOOD ASSY для Yamaha SIDEWINDER X TX 141 SE - 2017 года выпуска
-
№АртикулНазвание
-
18KC-F198A-00-00 HOOD ASSY 4 (DPBSE - PURPLISH BLUE)HOOD ASSY 4 (DPBSE - PURPLISH BLUE)
-
18KC-F198A-10-00 HOOD ASSY 4 (MDGR - MEDIUM GRAY)HOOD ASSY 4 (MDGR - MEDIUM GRAY)
-
28KC-K7122-00-00 ...HOOD 2 (DPBSE - PURPLISH BLUE)...HOOD 2 (DPBSE - PURPLISH BLUE)
-
28KC-K7122-10-00 ...HOOD 2 (MDGR - MEDIUM GRAY)...HOOD 2 (MDGR - MEDIUM GRAY)
-
38KC-F197A-00-00 HOOD ASSY 3 (DPBSE - PURPLISH BLUE)HOOD ASSY 3 (DPBSE - PURPLISH BLUE)
-
38KC-F197A-10-00 HOOD ASSY 3 (MDGR - MEDIUM GRAY)HOOD ASSY 3 (MDGR - MEDIUM GRAY)
-
48KC-K7121-00-00 ...HOOD 1 (DPBSE - PURPLISH BLUE)...HOOD 1 (DPBSE - PURPLISH BLUE)
-
48KC-K7121-10-00 ...HOOD 1 (MDGR - MEDIUM GRAY)...HOOD 1 (MDGR - MEDIUM GRAY)
-
58KC-K7111-00-00 SHROUD (DPBSE - PURPLISH BLUE)SHROUD (DPBSE - PURPLISH BLUE)
-
58MG-K7111-00-00 SHROUD (MDGR - MEDIUM GRAY)SHROUD (MDGR - MEDIUM GRAY)
-
68KC-K7112-00-00 SHROUD 2 (DPBSE - PURPLISH BLUE)SHROUD 2 (DPBSE - PURPLISH BLUE)
-
68MG-K7112-00-00 SHROUD 2 (MDGR - MEDIUM GRAY)SHROUD 2 (MDGR - MEDIUM GRAY)
-
78KC-K715B-00-00 INTAKE, LOWERINTAKE, LOWER
-
88KC-K715E-00-00 SCREEN, INTAKE DUCT 2SCREEN, INTAKE DUCT 2
-
98KC-K715D-00-00 SCREEN, INTAKE DUCT 1SCREEN, INTAKE DUCT 1
-
108KC-K715G-00-00 DUCT, INTAKE 2DUCT, INTAKE 2
-
118KC-K715F-00-00 DUCT, INTAKE 1DUCT, INTAKE 1
-
128KC-K715C-00-00 INTAKE, UPPERINTAKE, UPPER
-
138KC-K715J-00-00 VENT, FRONT 2VENT, FRONT 2
-
148KC-K715H-00-00 VENT, FRONT 1VENT, FRONT 1
-
158KC-K715K-00-00 DUCT, INTAKE FRONTDUCT, INTAKE FRONT
-
168KC-H5133-00-00 TAPE, REFLECTORTAPE, REFLECTOR
-
178JP-RA352-00-00 .NUT, CLIP 10.NUT, CLIP 10
-
188JP-RA2A2-00-00 SCREW, 13SCREW, 13
-
198KC-K715M-00-00 BEZEL, VENT 2BEZEL, VENT 2
-
208KC-K715L-00-00 BEZEL, VENT 1BEZEL, VENT 1
-
218KC-K715N-00-00 GRILLEGRILLE
-
228KC-K7123-00-00 GUIDE 1GUIDE 1
-
238KC-K715P-00-00 SHUT, INTAKESHUT, INTAKE
-
248KC-RA290-00-00 SCREWSCREW
-
258JP-RAK02-00-00 PIN, 2PIN, 2
-
268JP-RA202-00-00 SCREW, TAPPING 1/4-20X0.5SCREW, TAPPING 1/4-20X0.5
-
278KC-K715R-00-00 SEAL, INTAKESEAL, INTAKE
-
288KC-RA238-00-00 .SCREW, 4.SCREW, 4
-
298JP-RA345-00-00 NUT, 1NUT, 1
-
308KC-RA239-00-00 SCREW, 5SCREW, 5
-
318JP-RA203-00-00 SCREW, TAPPING 10-16X1/2SCREW, TAPPING 10-16X1/2
-
328KC-K810G-00-00 SIDE PANEL COMP. (R.H) (DPBSE - PURPLISH BLUE)SIDE PANEL COMP. (R.H) (DPBSE - PURPLISH BLUE)
-
328KC-K810G-10-00 SIDE PANEL COMP. (R.H) (MDGR - MEDIUM GRAY)SIDE PANEL COMP. (R.H) (MDGR - MEDIUM GRAY)
-
338KC-K8140-00-00 ...SHELL SIDE PANEL ASSY 2 (DPBSE - PURPLISH BLUE)...SHELL SIDE PANEL ASSY 2 (DPBSE - PURPLISH BLUE)
-
338KC-K8140-10-00 ...SHELL SIDE PANEL ASSY 2 (MDGR - MEDIUM GRAY)...SHELL SIDE PANEL ASSY 2 (MDGR - MEDIUM GRAY)
-
348KC-K7761-70-00 ...LABEL, WARNING 1...LABEL, WARNING 1
-
358JP-RA352-00-00 ...NUT, CLIP 10...NUT, CLIP 10
-
368KC-RA290-00-00 ...SCREW...SCREW
-
378KC-K715T-00-00 ...HOOK 2...HOOK 2
-
388KC-K7552-00-00 ...PROTECTOR 2...PROTECTOR 2
-
398KC-K7551-00-00 ...PROTECTOR 1...PROTECTOR 1
-
408KC-K7553-00-00 ...PROTECTOR 3...PROTECTOR 3
-
418KC-K7554-00-00 ...PROTECTOR 4...PROTECTOR 4
-
428KC-K7555-00-00 ...PROTECTOR 5...PROTECTOR 5
-
438KC-K715U-00-00 ...VENT, SIDE 1...VENT, SIDE 1
-
448KC-RA238-00-00 ...SCREW, 4...SCREW, 4
-
458KC-K7278-00-00 ...DAMPER, NOISE 18...DAMPER, NOISE 18
-
468KC-K810F-00-00 SIDE PANEL COMP. (L.H) (DPBSE - PURPLISH BLUE)SIDE PANEL COMP. (L.H) (DPBSE - PURPLISH BLUE)
-
468KC-K810F-10-00 SIDE PANEL COMP. (L.H) (MDGR - MEDIUM GRAY)SIDE PANEL COMP. (L.H) (MDGR - MEDIUM GRAY)
-
478KC-K8130-00-00 ...SHELL SIDE PANEL ASSY 1 (DPBSE - PURPLISH BLUE)...SHELL SIDE PANEL ASSY 1 (DPBSE - PURPLISH BLUE)
-
478KC-K8130-10-00 ...SHELL SIDE PANEL ASSY 1 (MDGR - MEDIUM GRAY)...SHELL SIDE PANEL ASSY 1 (MDGR - MEDIUM GRAY)
-
488KC-K7761-S0-00 ...LABEL, WARNING 1...LABEL, WARNING 1
-
498KC-K7279-00-00 ...DAMPER, NOISE 19...DAMPER, NOISE 19
-
508KC-K7277-00-00 ...DAMPER, NOISE 17...DAMPER, NOISE 17
-
518KC-K7277-10-00 ...DAMPER, NOISE 17...DAMPER, NOISE 17
-
528JP-RA352-00-00 ...NUT, CLIP 10...NUT, CLIP 10
-
538KC-RA290-00-00 ...SCREW...SCREW
-
548KC-K715S-00-00 ...HOOK 1...HOOK 1
-
558KC-RA238-00-00 .SCREW, 4.SCREW, 4
-
568KC-F1983-00-00 HOOD 2 (DPBSE - PURPLISH BLUE)HOOD 2 (DPBSE - PURPLISH BLUE)
-
568MG-F1983-00-00 HOOD 2 (MDGR - MEDIUM GRAY)HOOD 2 (MDGR - MEDIUM GRAY)
-
578KC-F198H-00-00 ...HOOD 4 (DPBSE - PURPLISH BLUE)...HOOD 4 (DPBSE - PURPLISH BLUE)
-
578MG-F198H-00-00 ...HOOD 4 (MDGR - MEDIUM GRAY)...HOOD 4 (MDGR - MEDIUM GRAY)
-
588KC-K7276-00-00 ...DAMPER, NOISE 16...DAMPER, NOISE 16
-
598KC-K7275-00-00 ...DAMPER, NOISE 15...DAMPER, NOISE 15
-
608KC-K7274-00-00 ...DAMPER, NOISE 14...DAMPER, NOISE 14
-
618KC-K7556-00-00 ...PROTECTOR 6...PROTECTOR 6
-
628KC-K7557-00-00 ...PROTECTOR 7...PROTECTOR 7
-
638JP-RA352-00-00 ...NUT, CLIP 10...NUT, CLIP 10
-
648KC-RA238-00-00 ...SCREW, 4...SCREW, 4
-
658KC-K7324-00-00 ...KNOB...KNOB
-
668JP-RA350-00-00 ...NUT, CLIP 1/4...NUT, CLIP 1/4
-
678KC-K7153-00-00 ...PLATE, BACK UP 1...PLATE, BACK UP 1
-
688JP-RA429-00-00 ...WASHER...WASHER
-
698JP-RAC15-00-00 ...CLIP, 6...CLIP, 6
-
708KC-K8181-00-00 PLATE 1PLATE 1
-
718KC-G1138-00-00 SEAL, EXT. 1SEAL, EXT. 1
-
728JP-RA523-00-00 RIVET, 14RIVET, 14
-
738KC-F1982-00-00 HOOD 1 (DPBSE - PURPLISH BLUE)HOOD 1 (DPBSE - PURPLISH BLUE)
-
738MG-F1982-00-00 HOOD 1 (MDGR - MEDIUM GRAY)HOOD 1 (MDGR - MEDIUM GRAY)
-
748KC-F197H-00-00 ...HOOD 3 (DPBSE - PURPLISH BLUE)...HOOD 3 (DPBSE - PURPLISH BLUE)
-
748MG-F197H-00-00 ...HOOD 3 (MDGR - MEDIUM GRAY)...HOOD 3 (MDGR - MEDIUM GRAY)
-
758KC-K7271-00-00 ...DAMPER, NOISE 11...DAMPER, NOISE 11
-
768KC-K7272-00-00 ...DAMPER, NOISE 12...DAMPER, NOISE 12
-
778KC-K7273-00-00 ...DAMPER, NOISE 13...DAMPER, NOISE 13
-
788JP-RA352-00-00 ...NUT, CLIP 10...NUT, CLIP 10
-
798KC-RA238-00-00 ...SCREW, 4...SCREW, 4
-
808KC-K7324-00-00 ...KNOB...KNOB
-
818JP-RA350-00-00 ...NUT, CLIP 1/4...NUT, CLIP 1/4
-
828KC-K7153-00-00 ...PLATE, BACK UP 1...PLATE, BACK UP 1
-
838JP-RA429-00-00 ...WASHER...WASHER
-
848JP-RAC15-00-00 ...CLIP, 6...CLIP, 6
