DIFFERENTIAL - FRONT для Yamaha RHINO 450 SPECIAL EDITION - 2008 года выпуска
-
№АртикулНазвание
-
12P5-46108-01-00 CROSS JOINT COMP. 3CROSS JOINT COMP. 3
-
293399-99948-00 ...BEARING...BEARING
-
393440-20088-00 ...CIRCLIP, OUTER...CIRCLIP, OUTER
-
45GT-46187-00-00 ...SPIDER...SPIDER
-
593399-99948-00 BEARINGBEARING
-
693440-20088-00 CIRCLIP, OUTERCIRCLIP, OUTER
-
75UG-46160-12-00 FRONT AXLE GEAR CASE COMP.FRONT AXLE GEAR CASE COMP.
-
85UG-46161-00-00 ...HOUSING, SHAFT DRIVE 2...HOUSING, SHAFT DRIVE 2
-
95UG-46162-00-00 ...HOUSING, BEARING 2...HOUSING, BEARING 2
-
105KM-46141-13-00 ...PINION, DRIVE 2...PINION, DRIVE 2
-
115KM-46146-11-00 ...YOKE, JOINT 2 (23 SP)...YOKE, JOINT 2 (23 SP)
-
124WV-46145-10-00 ...NUT 1...NUT 1
-
1393210-14359-00 ...O-RING...O-RING
-
1493105-46001-00 ...OIL SEAL...OIL SEAL
-
153B4-46163-00-00 ...SEAL,OIL 1...SEAL,OIL 1
-
164WV-46119-01-00 ...SHIM, THRUST (0.1T) (OPT)...SHIM, THRUST (0.1T) (OPT)
-
164WV-46119-11-00 ...SHIM, THRUST (0.2T) (OPT)...SHIM, THRUST (0.2T) (OPT)
-
164WV-46119-21-00 ...SHIM, THRUST (0.3T) (OPT)...SHIM, THRUST (0.3T) (OPT)
-
164WV-46119-31-00 ...SHIM, THRUST (0.4T) (OPT)...SHIM, THRUST (0.4T) (OPT)
-
164WV-46119-41-00 ...SHIM, THRUST (0.5T) (OPT)...SHIM, THRUST (0.5T) (OPT)
-
164WV-46119-51-00 ...SHIM, THRUST (1.0T) (OPT)...SHIM, THRUST (1.0T) (OPT)
-
175KM-46155-00-00 ...BOLT 1...BOLT 1
-
185KM-46470-13-00 ...LIMITED SLIP DIFF. ASSY...LIMITED SLIP DIFF. ASSY
-
1991317-08020-00 ...BOLT...BOLT
-
2090113-08004-00 ...BOLT, SET...BOLT, SET
-
214WV-46159-00-00 ...BOLT 3...BOLT 3
-
225KM-46143-00-00 ...RING, HOLE SNAP 2...RING, HOLE SNAP 2
-
235KM-42752-00-00 ...SHAFT...SHAFT
-
245KM-4616A-02-00 ...SERVO MOTOR COMP...SERVO MOTOR COMP
-
255KM-46441-00-00 ...CLUTCH, DRIVEN...CLUTCH, DRIVEN
-
265KM-18319-00-00 ...SHAFT 2...SHAFT 2
-
2793210-82001-00 ...O-RING...O-RING
-
2893211-40040-00 ...O-RING...O-RING
-
2993306-00709-00 ...BEARING...BEARING
-
3093306-91201-00 ...BEARING...BEARING
-
3193316-00702-00 ...BEARING...BEARING
-
324WV-46167-00-00 ...BEARING 4...BEARING 4
-
3390340-10001-00 ...PLUG, STRAIGHT SCREW...PLUG, STRAIGHT SCREW
-
3490430-10003-00 ...GASKET...GASKET
-
355KM-46451-00-00 ...ADAPTER...ADAPTER
-
365KM-46119-01-00 ...SHIM, THRUST (0.1T) (OPT)...SHIM, THRUST (0.1T) (OPT)
-
365KM-46119-11-00 ...SHIM, THRUST (0.2T) (OPT)...SHIM, THRUST (0.2T) (OPT)
-
365KM-46119-21-00 ...SHIM, THRUST (0.3T) (OPT)...SHIM, THRUST (0.3T) (OPT)
-
365KM-46119-31-00 ...SHIM, THRUST (0.4T) (OPT)...SHIM, THRUST (0.4T) (OPT)
-
365KM-46119-41-00 ...SHIM, THRUST (0.5T) (OPT)...SHIM, THRUST (0.5T) (OPT)
-
365KM-46119-51-00 ...SHIM, THRUST (1.0T) (OPT)...SHIM, THRUST (1.0T) (OPT)
-
365KM-46119-61-00 ...SHIM, THRUST (1.5T) (OPT)...SHIM, THRUST (1.5T) (OPT)
-
375KM-18514-00-00 ...FORK, SHIFT 4...FORK, SHIFT 4
-
382P5-46108-01-00 CROSS JOINT COMP. 3CROSS JOINT COMP. 3
-
3993399-99948-00 ...BEARING...BEARING
-
4093440-20088-00 ...CIRCLIP, OUTER...CIRCLIP, OUTER
-
415GT-46187-00-00 ...SPIDER...SPIDER
-
4293399-99948-00 BEARINGBEARING
-
4393440-20088-00 CIRCLIP, OUTERCIRCLIP, OUTER
-
4490340-14029-00 PLUG, STRAIGHT SCREWPLUG, STRAIGHT SCREW
-
45214-11198-01-00 GASKETGASKET
-
4690445-070G6-00 HOSE (L1700)HOSE (L1700)
-
4790467-07029-00 CLIP, SCISSORCLIP, SCISSOR
-
482P5-46173-00-00 SHAFT, DRIVE 2SHAFT, DRIVE 2
-
4999009-19400-00 CIRCLIP, S-TYPECIRCLIP, S-TYPE
-
5090201-20266-00 WASHER, PLATE (T=1.0)WASHER, PLATE (T=1.0)
-
5190501-235L9-00 SPRING, COMPRESSIONSPRING, COMPRESSION
-
525GT-46136-00-00 SEAL 1SEAL 1
-
535GT-46137-00-00 SEAL 2SEAL 2
-
5495812-10030-00 BOLT, FLANGEBOLT, FLANGE
-
5590201-10035-00 WASHER, PLATEWASHER, PLATE
-
5690105-10230-00 BOLT, FLANGEBOLT, FLANGE
-
5790185-10011-00 NUT, SELF-LOCKINGNUT, SELF-LOCKING
-
5890201-10035-00 WASHER, PLATEWASHER, PLATE
