OIL COOLER ASSEMBLY для Arctic Cat 400 4X4 VP AUTO (RED) [A2005ATH4BUSR] - 2005 года выпуска
-
№АртикулНазвание
-
10413-103 COOLER, OIL - ASSEMBLY (INC. 2-8)COOLER, OIL - ASSEMBLY (INC. 2-8)
-
20413-053 ...COOLER, OIL...COOLER, OIL
-
30413-059 ...O-RING...O-RING
-
40413-058 ...PLUG, DRAIN...PLUG, DRAIN
-
50413-064 ...SHROUD, FAN...SHROUD, FAN
-
68475-512 ...SCREW, MACHINE...SCREW, MACHINE
-
70413-044 ...FAN, COOLING...FAN, COOLING
-
80423-030 ...GROMMET...GROMMET
-
90623-038 NUT W/WASHERNUT W/WASHER
-
100423-484 SCREW, SHOULDERSCREW, SHOULDER
-
110423-028 BUSHING, STEMBUSHING, STEM
-
120423-098 CLAMP, HOSECLAMP, HOSE
-
130410-044 HOSE, OILHOSE, OIL
-
140410-013 FITTING, OILFITTING, OIL
-
150423-089 O-RING, OIL FITTINGO-RING, OIL FITTING
-
168471-616 SCREW, CAPSCREW, CAP
-
170410-012 FITTING, OIL - ANGLEDFITTING, OIL - ANGLED
