CARBURETOR ASSEMBLY для Arctic Cat DVX 90 [A2013KSB2BUSR] - 2013 года выпуска
-
№АртикулНазвание
-
-3306-433 COMPLETE CARBURETOR ASSEMBLYCOMPLETE CARBURETOR ASSEMBLY
-
13304-462 SET, TOP (INC. 2)SET, TOP (INC. 2)
-
23304-463 ...GASKET...GASKET
-
33304-464 SPRING, COMPRESSIONSPRING, COMPRESSION
-
43304-467 VALVE, THROTTLE - ASSEMBLY (INC. 5-6)VALVE, THROTTLE - ASSEMBLY (INC. 5-6)
-
53304-465 ...CLIP, SPRING...CLIP, SPRING
-
63304-466 ...E-RING...E-RING
-
73304-468 NEEDLE JETNEEDLE JET
-
83304-472 HOSE ASSEMBLY (INC. ONE NO. 9)HOSE ASSEMBLY (INC. ONE NO. 9)
-
95507-161 ...CLAMP, HOSE...CLAMP, HOSE
-
103304-469 COVERCOVER
-
113304-470 AUTOMATIC BYPASS/STARTER ASSEMBLYAUTOMATIC BYPASS/STARTER ASSEMBLY
-
125507-117 SCREW, MACHINESCREW, MACHINE
-
133304-471 PLATE, RETAININGPLATE, RETAINING
-
143304-488 O-RINGO-RING
-
153304-477 SCREW, STOP - ASSEMBLY (INC. 16-17)SCREW, STOP - ASSEMBLY (INC. 16-17)
-
163304-232 ...SPRING...SPRING
-
173304-478 ...SCREW, STOP...SCREW, STOP
-
183304-479 HOLDER, NEEDLE JET - ASSEMBLY (INC. 19)HOLDER, NEEDLE JET - ASSEMBLY (INC. 19)
-
193304-482 ...JET, MAIN - 80...JET, MAIN - 80
-
195507-170 ...JET, MAIN - 75 - OPTIONAL...JET, MAIN - 75 - OPTIONAL
-
195507-220 ...JET, MAIN - 78 - OPTIONAL...JET, MAIN - 78 - OPTIONAL
-
203304-489 JET, SLOWJET, SLOW
-
213304-490 VALVE, FLOAT - ASSEMBLY (INC. 22-23)VALVE, FLOAT - ASSEMBLY (INC. 22-23)
-
223304-483 ...VALVE, FLOAT...VALVE, FLOAT
-
233304-484 ...CLIP...CLIP
-
243304-491 FLOAT ASSEMBLYFLOAT ASSEMBLY
-
253304-485 PIN, FLOATPIN, FLOAT
-
263304-486 CHAMBER, FLOAT W/GASKET (INC. ONE NO. 9 AND 27-29)CHAMBER, FLOAT W/GASKET (INC. ONE NO. 9 AND 27-29)
-
273304-239 ...O-RING...O-RING
-
283304-243 ...SCREW, DRAIN...SCREW, DRAIN
-
293305-248 ...HOSE...HOSE
-
303303-320 SCREW, MACHINESCREW, MACHINE
