REAR SUSPENSION SHOCK ABSORBER ASSEMBLY для Arctic Cat WILDCAT TRAIL RED [U2015W5T4CUSR] - 2015 года выпуска
-
№АртикулНазвание
-
-0404-306 SHOCK ABSORBERSHOCK ABSORBER
-
13603-013 CAP, BODYCAP, BODY
-
23603-460 DECAL, "FOX"DECAL, "FOX"
-
33603-461 BUSHINGBUSHING
-
40403-491 SLEEVESLEEVE
-
50403-492 SLEEVESLEEVE
-
63603-021 VALVE, AIR - ASSEMBLYVALVE, AIR - ASSEMBLY
-
70603-438 O-RING-END CAPO-RING-END CAP
-
83603-462 BODY, SHOCKBODY, SHOCK
-
93603-023 PISTON, FLOATING - W/O-RINGPISTON, FLOATING - W/O-RING
-
103603-026 PRELOAD RINGPRELOAD RING
-
113603-027 PRELOAD RING, BACKUPPRELOAD RING, BACKUP
-
124604-016 GUIDE, SPRINGGUIDE, SPRING
-
133603-018 NUT, LOCKNUT, LOCK
-
142604-966 WASHER, TOP OUTWASHER, TOP OUT
-
150603-885 VALVE, 0.800 X 0.015 IN.VALVE, 0.800 X 0.015 IN.
-
160603-886 VALVE, 0.900 X 0.015 IN.VALVE, 0.900 X 0.015 IN.
-
170603-887 VALVE, 1.000 X 0.015 IN.VALVE, 1.000 X 0.015 IN.
-
180603-888 VALVE, 1.100 X 0.015 IN.VALVE, 1.100 X 0.015 IN.
-
190603-895 VALVE, 0.800 X 0.004 IN.VALVE, 0.800 X 0.004 IN.
-
200603-344 VALVE, 1.100 X 0.010 IN.VALVE, 1.100 X 0.010 IN.
-
213603-397 PISTON, 3-PORTPISTON, 3-PORT
-
220603-345 VALVE, 1.250 X 0.006 IN.VALVE, 1.250 X 0.006 IN.
-
230603-348 VALVE, 1.300 X 0.006 IN.VALVE, 1.300 X 0.006 IN.
-
240603-731 VALVE, 0.700 X 0.004 IN.VALVE, 0.700 X 0.004 IN.
-
250603-891 VALVE, 1.300 X 0.012 IN.VALVE, 1.300 X 0.012 IN.
-
260603-883 VALVE, 1.250 X 0.012 IN.VALVE, 1.250 X 0.012 IN.
-
270603-882 VALVE, 1.100 X 0.012 IN.VALVE, 1.100 X 0.012 IN.
-
280603-880 VALVE, 0.900 X 0.012 IN.VALVE, 0.900 X 0.012 IN.
-
290403-494 VALVE, 1.230 X 0.082 IN.VALVE, 1.230 X 0.082 IN.
-
303603-375 ROD, SHOCKROD, SHOCK
-
313603-458 BEARING - ASSEMBLYBEARING - ASSEMBLY
-
320604-521 RETAINER, RINGRETAINER, RING
-
330403-489 END CAP, SHOCK/RESERVOIREND CAP, SHOCK/RESERVOIR
-
343603-024 BUMPER, SHAFTBUMPER, SHAFT
-
353603-028 WASHERWASHER
-
360403-490 RETAINER, SPRINGRETAINER, SPRING
-
373603-016 EYELETEYELET
