STEERING ASSEMBLY для Arctic Cat WILDCAT TRAIL RED [U2015W5T4CUSR] - 2015 года выпуска
-
№АртикулНазвание
-
10505-690 CAP, STEERING WHEEL (INC. 2)CAP, STEERING WHEEL (INC. 2)
-
21411-798 ...DECAL, CAT...DECAL, CAT
-
30423-884 NUTNUT
-
40405-398 WHEEL, STEERINGWHEEL, STEERING
-
51423-045 CLIP, RETAININGCLIP, RETAINING
-
61423-110 RING, RETAININGRING, RETAINING
-
70828-071 WASHERWASHER
-
80423-558 WASHERWASHER
-
90505-891 TILT STEERING - SUB ASSEMBLY (INC. 10-11)TILT STEERING - SUB ASSEMBLY (INC. 10-11)
-
100405-405 ...BUSHING...BUSHING
-
110405-473 ...BUSHING...BUSHING
-
120423-669 SPACERSPACER
-
138408-831 SCREW, CAPSCREW, CAP
-
148427-802 NUT, LOCKNUT, LOCK
-
150405-468 LIFT, SUPPORTLIFT, SUPPORT
-
161423-250 SCREW, SHOULDERSCREW, SHOULDER
-
170623-056 NUT, LOCKNUT, LOCK
-
180405-489 SHAFT, STEERINGSHAFT, STEERING
-
198409-045 SCREW, CAPSCREW, CAP
-
208450-157 WASHERWASHER
-
218422-002 NUT, LOCKNUT, LOCK
-
228409-040 SCREW, CAPSCREW, CAP
-
238427-002 NUT, LOCKNUT, LOCK
-
248408-820 SCREW, CAPSCREW, CAP
-
258408-886 SCREW, CAPSCREW, CAP
-
268422-802 NUT, LOCKNUT, LOCK
-
270505-819 RACK AND PINION - ASSEMBLY (INC. 28-34)RACK AND PINION - ASSEMBLY (INC. 28-34)
-
280405-485 ...END, TIE ROD - INNER...END, TIE ROD - INNER
-
290405-505 ...CLAMP, BELLOW - LARGE...CLAMP, BELLOW - LARGE
-
300405-487 ...BELLOW - DRIVER SIDE...BELLOW - DRIVER SIDE
-
310405-488 ...BELLOW - PASSENGER SIDE...BELLOW - PASSENGER SIDE
-
320405-504 ...CLAMP, BELLOW - SMALL...CLAMP, BELLOW - SMALL
-
331423-226 ...NUT, JAM - OUTER...NUT, JAM - OUTER
-
340405-486 ...END, TIE ROD - OUTER...END, TIE ROD - OUTER
-
350423-072 NUTNUT
-
360623-175 PIN, COTTERPIN, COTTER
