GAS TANK ASSEMBLY для Arctic Cat PROWLER 700 XT EPS GREEN INTERNATIONAL [U2016R2T1POSX] - 2016 года выпуска
-
№АртикулНазвание
-
10570-309 TANK, GAS - ASSEMBLY (INC 2-5)TANK, GAS - ASSEMBLY (INC 2-5)
-
20470-541 ...GAS TANK CAP...GAS TANK CAP
-
31670-228 ...GASKET, GAS TANK CAP...GASKET, GAS TANK CAP
-
40423-898 ...SCREW, SELF-TAPPING...SCREW, SELF-TAPPING
-
52670-042 ...PLATE, RETAINING...PLATE, RETAINING
-
60570-435 PUMP, FUEL - ASSEMBLY (INC. 7)PUMP, FUEL - ASSEMBLY (INC. 7)
-
72670-235 ...FLOAT...FLOAT
-
80470-838 SEALSEAL
-
98476-620 SCREW, MACHINESCREW, MACHINE
-
100570-431 HOSE, GASLINEHOSE, GASLINE
-
111623-675 CLAMP, ROUTINGCLAMP, ROUTING
-
120410-070 HOSE - 25 FTHOSE - 25 FT
-
130470-829 BRACKET, HOLD-DOWN - RIGHTBRACKET, HOLD-DOWN - RIGHT
-
140623-784 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
158476-650 SCREW, MACHINESCREW, MACHINE
-
160470-830 BRACKET, HOLD-DOWN - LEFTBRACKET, HOLD-DOWN - LEFT
-
178427-602 NUT, LOCKNUT, LOCK
-
188476-616 SCREW, MACHINESCREW, MACHINE
-
190470-544 BRACKET, HOLD-DOWN - FRONTBRACKET, HOLD-DOWN - FRONT
-
200623-038 NUT W/WASHERNUT W/WASHER
-
210423-688 CLAMP, HOSECLAMP, HOSE
-
221770-170 FUEL LEVEL SENSOR KITFUEL LEVEL SENSOR KIT
