SHIFTER ASSEMBLY для Arctic Cat PROWLER 700 XT EPS GREEN INTERNATIONAL [U2016R2T1POSX] - 2016 года выпуска
-
№АртикулНазвание
-
14406-625 KNOB, SHIFTKNOB, SHIFT
-
20423-345 CLIP, PUSHCLIP, PUSH
-
32502-230 LEVER, SHIFT - (BLACK)LEVER, SHIFT - (BLACK)
-
42402-213 BUSHINGBUSHING
-
50423-505 SCREW, SHOULDERSCREW, SHOULDER
-
68427-805 NUT, LOCKNUT, LOCK
-
70423-356 SCREW, SHOULDERSCREW, SHOULDER
-
88427-605 NUTNUT
-
90487-098 CABLE, SHIFTCABLE, SHIFT
-
100623-677 TIE, CABLE - PUSH-MOUNTTIE, CABLE - PUSH-MOUNT
-
111502-843 BRACKET, SHIFT CABLEBRACKET, SHIFT CABLE
-
128468-635 SCREW, MACHINESCREW, MACHINE
-
130124-057 E-RINGE-RING
-
141423-134 SPACERSPACER
-
151423-135 SCREW, CAPSCREW, CAP
