STEERING ASSEMBLY для Arctic Cat XC 450 EFI [A2016KCK4CUST] - 2016 года выпуска
-
№АртикулНазвание
-
13307-066 BOLT FLANGE 8*55BOLT FLANGE 8*55
-
20405-035 CAP, STEERING ADJUSTERCAP, STEERING ADJUSTER
-
33305-496 BUSHING, STEERINGBUSHING, STEERING
-
43305-927 BLOCK, MOUNTING - STEERING POSTBLOCK, MOUNTING - STEERING POST
-
53304-649 BOLT FLANGE 8*60BOLT FLANGE 8*60
-
63306-459 POST, STEERINGPOST, STEERING
-
73304-565 BOLT, FLANGE - 8 X 20BOLT, FLANGE - 8 X 20
-
80602-233 FLANGE, BEARINGFLANGE, BEARING
-
90405-052 BEARING W/INVERTED OIL SEALBEARING W/INVERTED OIL SEAL
-
100423-073 WASHERWASHER
-
118408-820 SCREW, CAPSCREW, CAP
-
123306-722 TIE ROD - ASSEMBLY (INC. 13-17)TIE ROD - ASSEMBLY (INC. 13-17)
-
133306-725 ...END, TIE ROD - LEFT-HAND THREAD...END, TIE ROD - LEFT-HAND THREAD
-
143306-727 ...NUT - LEFT-HAND THREAD...NUT - LEFT-HAND THREAD
-
153306-723 ...TIE ROD...TIE ROD
-
163306-726 ...NUT - RIGHT-HAND THREAD...NUT - RIGHT-HAND THREAD
-
173306-724 ...END, TIE ROD - RIGHT-HAND THREAD...END, TIE ROD - RIGHT-HAND THREAD
-
183306-290 NUT CASTLE 10MMNUT CASTLE 10MM
-
193305-724 PIN, COTTERPIN, COTTER
