DRIVEN CLUTCH для Arctic Cat Pantera 1000 (USA) - 2000 года выпуска
-
№АртикулНазвание
-
-0726-092 CLUTCH, DRIVEN ASSEMBLYCLUTCH, DRIVEN ASSEMBLY
-
10748-023 SHEAVE, MOVABLE (INC. ONE NO. 8)SHEAVE, MOVABLE (INC. ONE NO. 8)
-
20748-021 SHEAVE, STATIONARYSHEAVE, STATIONARY
-
30648-016 BRACKET, TORQUE 57Ш/50ШBRACKET, TORQUE 57Ш/50Ш
-
30148-222 BRACKET, TORQUE 51Ш (5-9,000 FT ALT.)BRACKET, TORQUE 51Ш (5-9,000 FT ALT.)
-
30648-014 BRACKET, TORQUE 49Ш (OVER 9,000 FT ALT.)BRACKET, TORQUE 49Ш (OVER 9,000 FT ALT.)
-
48051-152 WASHER, LOCKWASHER, LOCK
-
58005-404 SCREW, CAP - SOCKET HEADSCREW, CAP - SOCKET HEAD
-
60148-227 SPRING, DRIVEN CLUTCH - YELLOWSPRING, DRIVEN CLUTCH - YELLOW
-
70748-018 PLATE, ROLLER ASSEMBLY (INC. 8-10 AND 12-14)PLATE, ROLLER ASSEMBLY (INC. 8-10 AND 12-14)
-
80648-009 BEARINGBEARING
-
98040-426 NUT, LOCKNUT, LOCK
-
108070-224 PIN, SPRINGPIN, SPRING
-
110148-198 WASHER, THRUST: 0.030 IN.WASHER, THRUST: 0.030 IN.
-
110148-199 WASHER, THRUST: 0.060 IN.WASHER, THRUST: 0.060 IN.
-
120648-082 WASHER, THRUST - CAM ROLLERWASHER, THRUST - CAM ROLLER
-
130648-123 ROLLER, CAMROLLER, CAM
-
140648-097 PIN, CAM ROLLERPIN, CAM ROLLER
-
150148-224 COVER, SHEAVE - MOVABLECOVER, SHEAVE - MOVABLE
-
160148-225 COVER, SHEAVE - STATIONARYCOVER, SHEAVE - STATIONARY
-
170623-786 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
