ALTERNATE CARBURETOR PARTS #2 для Arctic Cat ZRT 800 (Green) - 2000 года выпуска
-
№АртикулНазвание
-
-6505-180 NEEDLE JET (VM, STYLE) BB, 5 (224)NEEDLE JET (VM, STYLE) BB, 5 (224)
-
-6505-218 PILOT JET, 17.5PILOT JET, 17.5
-
-6505-138 PILOT JET, 20PILOT JET, 20
-
-6505-310 PILOT JET, 22.5PILOT JET, 22.5
-
-6505-075 PILOT JET, 25PILOT JET, 25
-
-6505-503 PILOT JET, 27.5PILOT JET, 27.5
-
-6505-073 PILOT JET, 30PILOT JET, 30
-
-6505-029 PILOT JET, 35PILOT JET, 35
-
-6505-047 PILOT JET, 40PILOT JET, 40
-
-6505-278 PILOT JET, 45PILOT JET, 45
-
-6505-262 PILOT JET, 50PILOT JET, 50
-
-6505-261 PILOT JET, 52.5PILOT JET, 52.5
-
-6505-255 PILOT JET, 55PILOT JET, 55
-
-6505-519 JET NEEDLE, 6CH3JET NEEDLE, 6CH3
-
-6505-252 JET NEEDLE, 6DH2JET NEEDLE, 6DH2
-
-6505-509 JET NEEDLE, 6DH3JET NEEDLE, 6DH3
-
-6505-003 JET NEEDLE, 6DH4JET NEEDLE, 6DH4
-
-6505-215 JET NEEDLE, 6DH7JET NEEDLE, 6DH7
-
-6505-236 JET NEEDLE, 6DH8JET NEEDLE, 6DH8
-
-6505-549 JET NEEDLE, 7DJ2JET NEEDLE, 7DJ2
-
-6505-097 JET NEEDLE, 7DH2JET NEEDLE, 7DH2
-
-6505-814 JET NEEDLE, 7DH5JET NEEDLE, 7DH5
-
-6505-026 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 28, 30, 32, 34INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 28, 30, 32, 34
-
-6505-160 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (VITON) ; CARB. SIZE (MM) : 28, 30, 32, 34INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (VITON) ; CARB. SIZE (MM) : 28, 30, 32, 34
-
-6505-245 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 28, 34 GVMINLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 28, 34 GVM
-
-6505-103 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 36, 38, 40, 44INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 36, 38, 40, 44
-
-6505-171 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44
-
-6505-175 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.8 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.8 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44
-
-6505-176 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 2.0 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 2.0 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44
-
-6506-121 INLET NEEDLE ASSY. (TM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 38INLET NEEDLE ASSY. (TM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 38
-
-6506-144 INLET NEEDLE ASSY. (TM, STYLE) SEAT DIA.: 1.8 MM (STEEL) ; CARB. SIZE (MM) : 38INLET NEEDLE ASSY. (TM, STYLE) SEAT DIA.: 1.8 MM (STEEL) ; CARB. SIZE (MM) : 38
-
-6505-048 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 28, 30PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 28, 30
-
-6505-161 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 28, 30PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 28, 30
-
-6505-510 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 30PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 30
-
-6505-528 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 30PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 30
-
-6505-256 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 1.5; CARBURETOR SIZE (MM) : 32, 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 1.5; CARBURETOR SIZE (MM) : 32, 34
-
-6505-246 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 32, 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 32, 34
-
-6505-439 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 32, 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 32, 34
-
-6505-248 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 32, 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 32, 34
-
-6505-500 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 34
-
-6505-614 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 34
-
-6505-507 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 34
-
-6505-561 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 34
-
-6505-877 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 36PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 36
-
-6505-592 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 36PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 36
-
-6505-254 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 38
-
-6505-643 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 38
-
-6505-436 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38
-
-6505-525 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38
-
-6505-526 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38
-
-6505-554 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38
