GEARCASE ASSEMBLY для Arctic Cat CROSSFIRE 600 EFI (ORANGE) - 2007 года выпуска
-
№АртикулНазвание
-
0702-896 COMPLETE GEARCASE ASSEMBLY (UP TO VIN: V47T106716)COMPLETE GEARCASE ASSEMBLY (UP TO VIN: V47T106716)
-
0702-936 COMPLETE GEARCASE ASSEMBLY (VIN: V47T106717 AND ABOVE)COMPLETE GEARCASE ASSEMBLY (VIN: V47T106717 AND ABOVE)
-
10702-889 GEARCASE (INC. 2-3)GEARCASE (INC. 2-3)
-
21602-915 ...PIN, DOWEL...PIN, DOWEL
-
32602-067 ...SEAL, OIL...SEAL, OIL
-
40702-891 BRACKET, MOUNTING - REVERSE ACTUATOR (INC. 5-6)BRACKET, MOUNTING - REVERSE ACTUATOR (INC. 5-6)
-
51602-916 ...BEARING...BEARING
-
60630-228 ...SWITCH, ALARM...SWITCH, ALARM
-
70423-538 SCREW, MACHINESCREW, MACHINE
-
80630-220 ACTUATOR, REVERSEACTUATOR, REVERSE
-
98468-536 SCREW, MACHINESCREW, MACHINE
-
100702-875 FORK, SHIFT - ASSEMBLY (INC. 11-13)FORK, SHIFT - ASSEMBLY (INC. 11-13)
-
112602-013 ...SEAL, OIL...SEAL, OIL
-
122602-057 ...RING, RETAINING...RING, RETAINING
-
132602-007 ...ARM, SHIFT FORK...ARM, SHIFT FORK
-
141602-847 BLOCK, SLIDERBLOCK, SLIDER
-
150702-910 SLIDER, OUTER - ASSEMBLY (INC. 16-20)SLIDER, OUTER - ASSEMBLY (INC. 16-20)
-
162602-040 ...RING, RETAINING...RING, RETAINING
-
172602-064 ...WASHER, THRUST...WASHER, THRUST
-
180702-758 ...SHAFT, OUTPUT (INC. 19)...SHAFT, OUTPUT (INC. 19)
-
202602-063 ...SLIDER, OUTER...SLIDER, OUTER
-
210702-848 GEAR, TRANSFER - 60/34T - ASSEMBLY (INC. 22-27 AND ONE NO. 28)GEAR, TRANSFER - 60/34T - ASSEMBLY (INC. 22-27 AND ONE NO. 28)
-
221602-842 ...BEARING...BEARING
-
232602-058 ...WASHER, SPACER...WASHER, SPACER
-
240702-867 ...GEAR, PLANETARY - ASSEMBLY...GEAR, PLANETARY - ASSEMBLY
-
251602-840 ...BEARING, THRUST...BEARING, THRUST
-
261602-841 ...WASHER, THRUST...WASHER, THRUST
-
270702-847 ...GEAR, TRANSFER (INC. ONE NO. 28)...GEAR, TRANSFER (INC. ONE NO. 28)
-
281602-981 ......BEARING......BEARING
-
290702-691 SHAFT, INPUT - 60T (INC. ONE NO. 28)SHAFT, INPUT - 60T (INC. ONE NO. 28)
-
300702-893 COVER, GEARCASE (INC. 31-36) (UP TO VIN: V47T106716)COVER, GEARCASE (INC. 31-36) (UP TO VIN: V47T106716)
-
300702-934 COVER, GEARCASE (INC. 31-36) (VIN: V47T106717 AND ABOVE)COVER, GEARCASE (INC. 31-36) (VIN: V47T106717 AND ABOVE)
-
311602-875 ...SEAL, OIL...SEAL, OIL
-
321602-982 ...BEARING...BEARING
-
330623-293 ...PLUG, GEARCASE...PLUG, GEARCASE
-
341602-213 ...O-RING...O-RING
-
350812-006 ...PLUG, DRAIN - MAGNETIC...PLUG, DRAIN - MAGNETIC
-
360830-017 ...GASKET, METAL...GASKET, METAL
-
378468-616 SCREW, MACHINE (UP TO VIN: V47T106716)SCREW, MACHINE (UP TO VIN: V47T106716)
-
371623-683 SCREW, MACHINE (VIN: V47T106717 AND ABOVE)SCREW, MACHINE (VIN: V47T106717 AND ABOVE)
-
**4639-628 FLUID, GEARCASE - 12 OZ (NOT ILLUSTRATED)FLUID, GEARCASE - 12 OZ (NOT ILLUSTRATED)
