GAS TANK- SEAT- AND TAILLIGHT ASSEMBLY для Arctic Cat Z 570 (ORANGE LX) - 2007 года выпуска
-
№АртикулНазвание
-
12718-073 SEAT ASSEMBLY - COMPLETE (INC. 2-19)SEAT ASSEMBLY - COMPLETE (INC. 2-19)
-
20770-690 ...TANK, GAS/SEAT-BASE - BLACK (INC. 3-12)...TANK, GAS/SEAT-BASE - BLACK (INC. 3-12)
-
31670-173 ......OUTLET, TANK......OUTLET, TANK
-
40670-289 ......TAPE, TEFLON......TAPE, TEFLON
-
56101-001 ......HOSE, GASLINE - 100 FT......HOSE, GASLINE - 100 FT
-
56101-009 ......HOSE, GASLINE - 50 FT......HOSE, GASLINE - 50 FT
-
60510-358 ......STRAINER, GAS TANK......STRAINER, GAS TANK
-
71670-325 ......GROMMET......GROMMET
-
81670-494 ......VENT, GAS TANK......VENT, GAS TANK
-
91670-199 ......CAP, GAS TANK (INC. 10)......CAP, GAS TANK (INC. 10)
-
101670-228 .........SEAL, GAS TANK CAP.........SEAL, GAS TANK CAP
-
111670-241 ......GAUGE, GAS W/SEAL (INC. 12)......GAUGE, GAS W/SEAL (INC. 12)
-
120470-400 .........SEAL, GAS GAUGE.........SEAL, GAS GAUGE
-
133706-361 ...COVER, SEAT (INC. 14)...COVER, SEAT (INC. 14)
-
143606-363 ......WIRE, SEAT......WIRE, SEAT
-
150624-528 ...STAPLE, SEAT COVER...STAPLE, SEAT COVER
-
161606-126 ...INSERT, SEAT FOAM...INSERT, SEAT FOAM
-
172706-196 ...FOAM, SEAT CUSHION...FOAM, SEAT CUSHION
-
182606-943 ...WIRE, SEAT...WIRE, SEAT
-
190623-784 ...SCREW, SELF-TAPPING...SCREW, SELF-TAPPING
-
200623-404 CAP, PROTECTORCAP, PROTECTOR
-
218047-366 NUT, LOCKNUT, LOCK
-
228020-041 SCREW, CAPSCREW, CAP
-
230617-136 SEAL, FOAM - SEAT-BASESEAL, FOAM - SEAT-BASE
-
240623-038 NUT W/WASHERNUT W/WASHER
-
253002-964 CLAMP, WIRECLAMP, WIRE
-
260623-184 WASHERWASHER
-
270609-092 GASKET, TAILLIGHT LENSGASKET, TAILLIGHT LENS
-
280109-460 BULBBULB
-
290609-091 TAILLIGHT W/SOCKET ASSEMBLYTAILLIGHT W/SOCKET ASSEMBLY
-
300609-093 SCREW, RETAININGSCREW, RETAINING
-
310609-090 LENS, TAILLIGHTLENS, TAILLIGHT
-
321623-042 CLAMP, HOSECLAMP, HOSE
-
330623-101 CLIP, ROUTING - SNAP-INCLIP, ROUTING - SNAP-IN
