DRIVE TRAIN SHAFT AND BRAKE ASSEMBLIES для Arctic Cat AC CROSSFIRE 1000 EFI - 2009 года выпуска
-
№АртикулНазвание
-
11602-957 NUT, RETAININGNUT, RETAINING
-
21623-461 SCREW, CAPSCREW, CAP
-
31602-656 DISC, BRAKEDISC, BRAKE
-
41602-497 SPACER, BRAKE CALIPERSPACER, BRAKE CALIPER
-
52602-076 SHIELD, BEARINGSHIELD, BEARING
-
60728-182 TRACK, DRIVE - ASSEMBLY (INC. 7-8)TRACK, DRIVE - ASSEMBLY (INC. 7-8)
-
70702-940 ...DRIVESHAFT...DRIVESHAFT
-
82602-253 ...SPROCKET, DRIVE...SPROCKET, DRIVE
-
92602-065 SPACERSPACER
-
101602-984 SEALSEAL
-
110702-882 PLATE, MOUNTING - GEARCASEPLATE, MOUNTING - GEARCASE
-
121623-355 NUT, PUSHNUT, PUSH
-
131702-085 GEARCASE ASSEMBLYGEARCASE ASSEMBLY
-
148047-426 NUT, LOCKNUT, LOCK
-
150726-284 CLUTCH, DRIVENCLUTCH, DRIVEN
-
160648-441 O-RINGO-RING
-
170648-714 WASHERWASHER
-
170648-715 WASHERWASHER
-
170648-716 WASHERWASHER
-
181702-114 ADJUSTER, SHEAVE (INC. 19)ADJUSTER, SHEAVE (INC. 19)
-
190648-788 ...WASHER, THRUST...WASHER, THRUST
-
208050-277 WASHERWASHER
-
218051-272 WASHER, LOCKWASHER, LOCK
-
221623-572 SCREW, CAPSCREW, CAP
-
231702-014 CALIPER, BRAKE - ASSEMBLY (INC. 24-42)CALIPER, BRAKE - ASSEMBLY (INC. 24-42)
-
241623-360 ...BOLT, CARRIAGE - RIBBED...BOLT, CARRIAGE - RIBBED
-
261602-458 ...FITTING, BLEED...FITTING, BLEED
-
271602-461 ...PISTON...PISTON
-
281602-669 ...O-RING...O-RING
-
290702-563 ...PAD, BRAKE - SET (INC. 30-31)...PAD, BRAKE - SET (INC. 30-31)
-
301602-466 ......CLIP, ANTI-RATTLE......CLIP, ANTI-RATTLE
-
311602-467 ......CLIP, HAIRPIN......CLIP, HAIRPIN
-
321602-464 ...PIN, RETAINING - BRAKE PAD...PIN, RETAINING - BRAKE PAD
-
340602-729 ...O-RING, HOUSING...O-RING, HOUSING
-
350402-165 ...WASHER...WASHER
-
361602-671 ...SCREW, CAP...SCREW, CAP
-
371602-670 ...SCREW, CAP...SCREW, CAP
-
382602-132 ...SPACER, SPEEDOMETER BRACKET...SPACER, SPEEDOMETER BRACKET
-
392602-131 ...BEARING...BEARING
-
401602-463 ...SLEEVE, DRIVESHAFT...SLEEVE, DRIVESHAFT
-
411602-456 ...RING, RETAINING...RING, RETAINING
-
420602-590 ...FITTING, ADAPTER...FITTING, ADAPTER
-
434606-309 PLATE, MOUNTING - SPEEDOMETER SENSORPLATE, MOUNTING - SPEEDOMETER SENSOR
-
448468-617 SCREW, MACHINESCREW, MACHINE
-
451623-676 CLAMP, SPEEDOMETER SENSORCLAMP, SPEEDOMETER SENSOR
-
460630-207 SENSOR, SPEEDOMETERSENSOR, SPEEDOMETER
-
478060-602 RIVETRIVET
