GAS TANK ASSEMBLY для Arctic Cat BEARCAT 5000 XT LTD (BLACK) [S2015BCNWLUSB] - 2015 года выпуска
![](/wa-data/public/shop/sheme/arctic-cat/snow/3442059a-428e-4742-a10e-22813a280abd.gif)
-
№АртикулНазвание
-
10770-910 TANK, GAS - ASSEMBLY (INC. 2-5)TANK, GAS - ASSEMBLY (INC. 2-5)
-
20470-438 ...CAP, GAS TANK (INC. 3)...CAP, GAS TANK (INC. 3)
-
30109-733 ......GASKET, GAS TANK CAP......GASKET, GAS TANK CAP
-
41670-787 ...VALVE, CHECK...VALVE, CHECK
-
51670-822 ...GROMMET...GROMMET
-
61623-233 CLAMP, HOSECLAMP, HOSE
-
76101-001 HOSE, GASLINE - (100 FT)HOSE, GASLINE - (100 FT)
-
76101-009 HOSE, GASLINE - (50 FT)HOSE, GASLINE - (50 FT)
-
84706-746 KNEE PAD, RIGHTKNEE PAD, RIGHT
-
84706-747 KNEE PAD, LEFTKNEE PAD, LEFT
-
98470-510 SCREW, MACHINESCREW, MACHINE
-
100423-101 SCREW, SHOULDERSCREW, SHOULDER
-
110423-577 CLIP, U-NUTCLIP, U-NUT
-
120619-946 TAPE,DOUBLE COATED-ACYLIC FOAM(1 IN LENGTH)TAPE,DOUBLE COATED-ACYLIC FOAM(1 IN LENGTH)
