SKI AND SPINDLE ASSEMBLY для Arctic Cat M 8000 153 (GREEN) [S2015M8HE3USG] - 2015 года выпуска
-
№АртикулНазвание
-
13703-100 SPINDLE, STEERING - RIGHT - (TEAM ARCTIC GREEN) (INC. 2)SPINDLE, STEERING - RIGHT - (TEAM ARCTIC GREEN) (INC. 2)
-
13703-101 SPINDLE, STEERING - LEFT - (TEAM ARCTIC GREEN) (INC. 2)SPINDLE, STEERING - LEFT - (TEAM ARCTIC GREEN) (INC. 2)
-
20603-158 ...BEARING,GARLOCK 12DU12...BEARING,GARLOCK 12DU12
-
32603-813 AXLE, SPINDLEAXLE, SPINDLE
-
42603-208 SPACER,SKI-ADJ STANCE-PLASTICSPACER,SKI-ADJ STANCE-PLASTIC
-
53603-237 DAMPER, SKI-RUBBERDAMPER, SKI-RUBBER
-
63603-236 SKI, PLASTIC - (BLACK)SKI, PLASTIC - (BLACK)
-
72603-746 INSERT, SKI - 10 MMINSERT, SKI - 10 MM
-
83603-228 HANDLE, PLASTIC - (TEAM ARCTIC GREEN)HANDLE, PLASTIC - (TEAM ARCTIC GREEN)
-
98427-602 NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & YNUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y
-
108476-625 SCREW,MACH-TSTRH M6X1.0X25 Z & YSCREW,MACH-TSTRH M6X1.0X25 Z & Y
-
118476-650 SCREW,MACH-TSTRH M6X1.0X50 Z & YSCREW,MACH-TSTRH M6X1.0X50 Z & Y
-
120703-871 WEARBAR SKAG, 4" CARBIDE-PTD (BLACK)WEARBAR SKAG, 4" CARBIDE-PTD (BLACK)
-
138047-486 NUT,HEX FLG-NY LOCK 3/8-16 GR F Z & YNUT,HEX FLG-NY LOCK 3/8-16 GR F Z & Y
-
140423-744 NUT,HEX FLANGE-NSL M10X1.25 W/ 204 PATCHNUT,HEX FLANGE-NSL M10X1.25 W/ 204 PATCH
-
151623-801 WASHER,FLAT-M10-10.98 X 28.00 X 1.6 Z & YWASHER,FLAT-M10-10.98 X 28.00 X 1.6 Z & Y
-
160123-458 PIN, COTTERPIN, COTTER
-
171623-781 BOLT,SKI-HFH M10- 1.25 X 137 CL10.9BOLT,SKI-HFH M10- 1.25 X 137 CL10.9
