SUSPENSION REAR - FRONT ARM SHOCK ABSORBER для Arctic Cat M 8000 MCCLURE LTD 153 (ORANGE) [S2015M8HDMUSO] - 2015 года выпуска
-
№АртикулНазвание
-
-2704-706 COMPLETE SHOCK ABSORBERCOMPLETE SHOCK ABSORBER
-
13604-797 EYELET,SHOCK-FRT ARM-FORGEDEYELET,SHOCK-FRT ARM-FORGED
-
23604-763 ROD, SHOCKROD, SHOCK
-
34604-125 BEARING, ENDCAP - SHORT W/BLEED - ASSEMBLYBEARING, ENDCAP - SHORT W/BLEED - ASSEMBLY
-
44604-121 SEAL/BEARING - REBUILD KIT-37MMSEAL/BEARING - REBUILD KIT-37MM
-
53604-789 WASHER.TOP OUT-29.5 OD X 9.60 ID X 2 THKWASHER.TOP OUT-29.5 OD X 9.60 ID X 2 THK
-
63603-122 VALVE, 1.000 X 0.006 IN.VALVE, 1.000 X 0.006 IN.
-
73603-124 VALVE, 1.000 X 0.008 IN.VALVE, 1.000 X 0.008 IN.
-
83603-144 VALVE, 1.100 X 0.008 IN.VALVE, 1.100 X 0.008 IN.
-
93603-174 VALVE, 1.250 X 0.008 IN.VALVE, 1.250 X 0.008 IN.
-
103603-184 VALVE, 1.300 X 0.008 IN.VALVE, 1.300 X 0.008 IN.
-
113603-105 VALVE, 0.800 X 0.010 IN.VALVE, 0.800 X 0.010 IN.
-
123603-182 VALVE, 1.300 X 0.006 IN.VALVE, 1.300 X 0.006 IN.
-
132603-998 PISTON, 0.063 IN. - ORIFICEPISTON, 0.063 IN. - ORIFICE
-
143603-175 VALVE, 1.250 X 0.010 IN.VALVE, 1.250 X 0.010 IN.
-
153603-114 VALVE, 0.900 X 0.008 IN.VALVE, 0.900 X 0.008 IN.
-
163603-104 VALVE, 0.800 X 0.008 IN.VALVE, 0.800 X 0.008 IN.
-
173603-092 VALVE, 0.700 X 0.006 IN.VALVE, 0.700 X 0.006 IN.
-
182603-015 VALVE, 0.550 X 0.020 IN.VALVE, 0.550 X 0.020 IN.
-
193604-775 WASHER, BACKUP-15.8 OD X 2.4 X (9.6 ID)WASHER, BACKUP-15.8 OD X 2.4 X (9.6 ID)
-
203604-739 NUT, HEX - 3/8"-24UNFNUT, HEX - 3/8"-24UNF
-
213604-772 PISTON.FLOAT-ASSEMBLYPISTON.FLOAT-ASSEMBLY
-
223604-773 SLEEVE, WEARSLEEVE, WEAR
-
232603-014 RING,PRELOAD LOCK-SHOULDEREDRING,PRELOAD LOCK-SHOULDERED
-
243604-779 COLLAR, LOCKING - ADJUSTER NUTCOLLAR, LOCKING - ADJUSTER NUT
-
253604-758 BODY,SHOCK-ALUM-37.20 BORE- 143.80BODY,SHOCK-ALUM-37.20 BORE- 143.80
-
261621-728 DECAL, WARNING - HIGH PRESSUREDECAL, WARNING - HIGH PRESSURE
-
272704-257 END CAP, SHOCK - ASSEMBLY (INC. 28-29)END CAP, SHOCK - ASSEMBLY (INC. 28-29)
-
283604-751 ...VALVE, PRESSURE (INC. 29)...VALVE, PRESSURE (INC. 29)
-
293604-733 ......O-RING, VALVE......O-RING, VALVE
-
303604-750 SCREW.MACH-#8-32 X 5MM-SSSCREW.MACH-#8-32 X 5MM-SS
-
313604-906 BEARING,SHOCK FRT ARM-25.45 X 22.4X18.54BEARING,SHOCK FRT ARM-25.45 X 22.4X18.54
-
325639-530 SEMI-SYN SHOCK OIL-1 QUARTSEMI-SYN SHOCK OIL-1 QUART
