TUNNEL- REAR BUMPER- AND SNOWFLAP ASSEMBLY для Arctic Cat XF 7000 SNO PRO 137 (INTERNATIONAL) (GREEN) [S2015XFUSPOSG] - 2015 года выпуска
-
№АртикулНазвание
-
-2707-083 COMPLETE CHASSIS ASSEMBLYCOMPLETE CHASSIS ASSEMBLY
-
12707-383 TUNNEL ASSEMBLY (INC. 2-13)TUNNEL ASSEMBLY (INC. 2-13)
-
21707-952 ...TUNNEL, FRONT - ASSEMBLY (INC. 3-4)...TUNNEL, FRONT - ASSEMBLY (INC. 3-4)
-
31607-332 ......BRACKET, REAR SUSPENSION - OUTER RIGHT......BRACKET, REAR SUSPENSION - OUTER RIGHT
-
31607-333 ......BRACKET, REAR SUSPENSION - OUTER LEFT......BRACKET, REAR SUSPENSION - OUTER LEFT
-
48060-686 ......RIVET,BLIND-DH SS64 ZINC......RIVET,BLIND-DH SS64 ZINC
-
51623-206 ...RIVET,3/16 HUCK-M9...RIVET,3/16 HUCK-M9
-
68422-502 ...NUT, M5 X 1 NYL Z & Y...NUT, M5 X 1 NYL Z & Y
-
71707-644 ...BRACKET, MOUNTING - REAR SPAR - RIGHT...BRACKET, MOUNTING - REAR SPAR - RIGHT
-
71707-645 ...BRACKET, MOUNTING - REAR SPAR - LEFT...BRACKET, MOUNTING - REAR SPAR - LEFT
-
88476-512 ...SCREW,MACH-TSTRH M5X0.8X12 Z & Y...SCREW,MACH-TSTRH M5X0.8X12 Z & Y
-
91623-257 ...RIVET,3/16 HUCK-M5...RIVET,3/16 HUCK-M5
-
108060-682 ...RIVET,BLIND-DH SS62 ZINC...RIVET,BLIND-DH SS62 ZINC
-
111607-395 ...TUNNEL, REAR...TUNNEL, REAR
-
128060-484 ...RIVET, BLIND-DH SS53 ZINC...RIVET, BLIND-DH SS53 ZINC
-
131607-104 ...END CAP, TUNNEL...END CAP, TUNNEL
-
141623-984 CLAMP, WIRE - 76.14MM LG W/6.25 HOLECLAMP, WIRE - 76.14MM LG W/6.25 HOLE
-
150608-631 PLATE, RETAININGPLATE, RETAINING
-
168060-688 RIVET,BLIND-DH SS66 ZINCRIVET,BLIND-DH SS66 ZINC
-
178476-820 SCREW,MACH-TSTRH M8X1.25X20 Z & YSCREW,MACH-TSTRH M8X1.25X20 Z & Y
-
186606-664 SUPPORT, GAS TANK - RIGHTSUPPORT, GAS TANK - RIGHT
-
186606-665 SUPPORT, GAS TANK - LEFTSUPPORT, GAS TANK - LEFT
-
191707-454 SUPPORT, FOOTREST - RIGHT - (BLACK)SUPPORT, FOOTREST - RIGHT - (BLACK)
-
191707-455 SUPPORT, FOOTREST - LEFT - (BLACK)SUPPORT, FOOTREST - LEFT - (BLACK)
-
208427-802 NUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & YNUT,HEX FLG-NYL LOCK M8X1.25 CL8 Z & Y
-
210744-064 KIT,TOOL BAG-4 STROKE-ASSEMBLYKIT,TOOL BAG-4 STROKE-ASSEMBLY
-
228468-535 SCREW,MACH-TSPNH M5X0.8X35 CL8.8 (BLACK)SCREW,MACH-TSPNH M5X0.8X35 CL8.8 (BLACK)
-
231623-637 CLIP, U-NUTCLIP, U-NUT
-
240607-996 FOOTREST - RIGHTFOOTREST - RIGHT
-
240607-997 FOOTREST - LEFTFOOTREST - LEFT
-
258470-516 SCREW,MACH-TSPNH M5X.8X16 CL8.8 Z & YSCREW,MACH-TSPNH M5X.8X16 CL8.8 Z & Y
-
261607-109 PROTECTOR, CHAIN CASEPROTECTOR, CHAIN CASE
-
278061-708 RIVET, BLIND-LF SS66 (BLACK)RIVET, BLIND-LF SS66 (BLACK)
-
280607-351 PROTECTOR, BRAKE DISCPROTECTOR, BRAKE DISC
-
291607-371 SHIELD, BRAKE DISCSHIELD, BRAKE DISC
-
308408-613 SCREW,CAP-HFH M6X1.0X12 CL8.8 Z & Y W/2353SCREW,CAP-HFH M6X1.0X12 CL8.8 Z & Y W/2353
-
318470-520 SCREW,MACH-TSPNH M5X.8X20 CL8.8 Z & YSCREW,MACH-TSPNH M5X.8X20 CL8.8 Z & Y
-
321623-130 RIVET,3/16 HUCK-M4RIVET,3/16 HUCK-M4
-
331607-092 ROLL, TUNNELROLL, TUNNEL
-
340630-316 PROTECTOR, HARNESS - TAILLIGHT EXTENSIONPROTECTOR, HARNESS - TAILLIGHT EXTENSION
-
351623-241 RIVET,3/16 HUCK-M6RIVET,3/16 HUCK-M6
-
361607-162 GUSSET, RUNNING BOARD - RIGHTGUSSET, RUNNING BOARD - RIGHT
-
361607-163 GUSSET, RUNNING BOARD - LEFTGUSSET, RUNNING BOARD - LEFT
-
371607-040 GUSSET, TUNNEL ROLL - RIGHTGUSSET, TUNNEL ROLL - RIGHT
-
371607-041 GUSSET, TUNNEL ROLL - LEFTGUSSET, TUNNEL ROLL - LEFT
-
380621-990 DECAL, REFLECTOR - (RED)DECAL, REFLECTOR - (RED)
-
391621-488 DECAL, TUNNEL - RIGHTDECAL, TUNNEL - RIGHT
-
391621-489 DECAL, TUNNEL - LEFTDECAL, TUNNEL - LEFT
-
400630-328 HOUSING, TAILLIGHTHOUSING, TAILLIGHT
-
418470-510 SCREW,MACH-TSPNH M5X.8X10 CL8.8 Z & YSCREW,MACH-TSPNH M5X.8X10 CL8.8 Z & Y
-
420609-898 TAILLIGHT, LED (RED)TAILLIGHT, LED (RED)
-
436606-394 SNOWFLAP (BLACK)SNOWFLAP (BLACK)
-
445611-852 DECAL, WARNING - TOWING (FRENCH)DECAL, WARNING - TOWING (FRENCH)
-
455611-853 DECAL, WARNING - TOWING (ENGLISH)DECAL, WARNING - TOWING (ENGLISH)
-
468061-706 RIVET,BLIND-LF SS64 (BLACK)RIVET,BLIND-LF SS64 (BLACK)
-
472707-584 BUMPER,REAR-137"-PTD-(BLACK)BUMPER,REAR-137"-PTD-(BLACK)
-
488476-620 SCREW,MACH-TSTRH M6X1.0X20 Z & YSCREW,MACH-TSTRH M6X1.0X20 Z & Y
-
498427-602 NUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & YNUT,HEX FLG-NYL LOCK M6X1.0 CL8 Z & Y
-
506606-615 BAG, BELTBAG, BELT
-
516606-814 PAD, FUEL TANK - RIGHTPAD, FUEL TANK - RIGHT
-
516606-815 PAD, FUEL TANK - LEFTPAD, FUEL TANK - LEFT
-
521607-455 PROTECTOR, TUNNELPROTECTOR, TUNNEL
-
536606-816 PAD, FUEL TANK - CENTERPAD, FUEL TANK - CENTER
