CRANKCASE ASSEMBLY для Arctic Cat ZR 5000 LXR EARLY BUILD (GREEN) [S2015ZRNLXUSG] - 2015 года выпуска
-
№АртикулНазвание
-
13007-854 CRANKCASE ASSEMBLY (INC. 2)CRANKCASE ASSEMBLY (INC. 2)
-
23004-822 ...PIN, DOWEL...PIN, DOWEL
-
33007-498 BOLT, STUDBOLT, STUD
-
43402-444 GASKETGASKET
-
53007-407 BOLT,GROUNDBOLT,GROUND
-
63007-083 GASKET, OIL PLUGGASKET, OIL PLUG
-
73423-452 PLUG, OILPLUG, OIL
-
83402-556 GASKET, OIL LAMP SWITCHGASKET, OIL LAMP SWITCH
-
93007-501 PLUG, DRAINPLUG, DRAIN
-
103403-106 GASKET,IDLER SHAFTGASKET,IDLER SHAFT
-
113007-085 PLUG, OILPLUG, OIL
-
123007-086 O-RING, CRANKCASEO-RING, CRANKCASE
-
133007-087 SCREW, CAPSCREW, CAP
-
143007-088 SCREW, CAPSCREW, CAP
-
153007-681 BOLT,CRANKCASE (10X105)BOLT,CRANKCASE (10X105)
-
163007-411 BOLTBOLT
-
173007-401 SCREW, CAPSCREW, CAP
-
183007-408 BOLTBOLT
-
193007-090 PLATE, OIL SEPARATOR - RIGHTPLATE, OIL SEPARATOR - RIGHT
-
203007-091 PLATE, OIL SEPARATOR - LEFTPLATE, OIL SEPARATOR - LEFT
-
213007-092 SCREW, CAPSCREW, CAP
-
223007-855 SCREW, CAPSCREW, CAP
-
233007-093 FITTINGFITTING
-
243402-013 GASKET, M16X22X2GASKET, M16X22X2
-
253423-051 O-RINGO-RING
-
263007-094 JET, PISTON COOLINGJET, PISTON COOLING
