SUSPENSION FRONT - SHOCK ABSORBER для Arctic Cat ZR 6000 R SX (GREEN) [S2015ACDPRUSG] - 2015 года выпуска

№

Артикул

Название
-

3703-348 SHOCK ABSORBER - RIGHT

SHOCK ABSORBER - RIGHT

130 ₽
-

3703-349 SHOCK ABSORBER - LEFT

SHOCK ABSORBER - LEFT

130 ₽
1

3604-147 RING, RETAINING

RING, RETAINING

2 490 ₽
2

1604-664 BEARING

BEARING

6 860 ₽
3

3603-381 END CAP, SHOCK - RIGHT

END CAP, SHOCK - RIGHT

26 410 ₽
3

3603-395 END CAP, SHOCK - LEFT

END CAP, SHOCK - LEFT

27 240 ₽
4

3603-420 ...KIT, SEAL/BEARING REBUILD (INC. 5)

...KIT, SEAL/BEARING REBUILD (INC. 5)

25 580 ₽
5

3603-371 ...PISTON, INTERNAL FLOATING

...PISTON, INTERNAL FLOATING

6 860 ₽
6

3603-384 DAMPING, ADJUSTER

DAMPING, ADJUSTER

4 150 ₽
7

3603-386 KNOB, DAMPING ADJUSTER - REBOUND

KNOB, DAMPING ADJUSTER - REBOUND

1 100 ₽
8

3603-377 SCREW, MACHINE

SCREW, MACHINE

1 870 ₽
9

3603-367 CAP, AIR VALVE

CAP, AIR VALVE

610 ₽
10

2603-965 SEAL

SEAL

250 ₽
11

2603-511 VALVE, AIR

VALVE, AIR

4 990 ₽
12

3603-002 RESERVOIR

RESERVOIR

8 310 ₽
13

3603-373 DECAL, "EVOL"

DECAL, "EVOL"

3 110 ₽
14

3603-372 END CAP, RESERVOIR

END CAP, RESERVOIR

4 990 ₽
15

3603-290 BODY, SHOCK - UPPER (INC. 4 AND 16)

BODY, SHOCK - UPPER (INC. 4 AND 16)

35 980 ₽
16

3603-376 ...BEARING

...BEARING

3 320 ₽
17

3603-369 DECAL, "FOX"

DECAL, "FOX"

2 700 ₽
18

3603-005 BUMPER, SHOCK

BUMPER, SHOCK

2 910 ₽
19

3603-409 BEARING - ASSEMBLY

BEARING - ASSEMBLY

12 470 ₽
20

1603-940 SCREW, SET

SCREW, SET

190 ₽
21

3603-008 SPACER

SPACER

4 780 ₽
22

3603-467 ROD, DAMPING ADJUSTER

ROD, DAMPING ADJUSTER

11 020 ₽
23

3603-465 ROD, SHOCK - ASSEMBLY

ROD, SHOCK - ASSEMBLY

13 100 ₽
24

3603-394 SPRING ASSEMBLY

SPRING ASSEMBLY

10 810 ₽
25

0603-540 WASHER, TOP OUT-1.125OD X .378 ID X.093

WASHER, TOP OUT-1.125OD X .378 ID X.093

2 490 ₽
26

0603-887 VALVE, (1.000 X 0.015 IN.)

VALVE, (1.000 X 0.015 IN.)

1 040 ₽
27

0603-347 VALVE, (1.250 X 0.010 IN.)

VALVE, (1.250 X 0.010 IN.)

2 070 ₽
28

0603-891 VALVE, (1.300 X 0.012 IN.)

VALVE, (1.300 X 0.012 IN.)

1 870 ₽
29

0603-895 VALVE, (0.800 X 0.004 IN.)

VALVE, (0.800 X 0.004 IN.)

1 000 ₽
30

3603-009 VALVE, RING - (1.250 X 0.015 IN.)

VALVE, RING - (1.250 X 0.015 IN.)

1 870 ₽
31

0603-350 VALVE, (1.300 X 0.010 IN.)

VALVE, (1.300 X 0.010 IN.)

2 700 ₽
32

0603-349 VALVE, (1.300 X 0.008 IN.)

VALVE, (1.300 X 0.008 IN.)

2 070 ₽
33

0603-348 VALVE, (1.300 X 0.006 IN).

VALVE, (1.300 X 0.006 IN).

2 070 ₽
34

2603-987 PISTON, HIGH FLOW

PISTON, HIGH FLOW

5 820 ₽
35

0603-343 VALVE, (1.100 X 0.008 IN.)

VALVE, (1.100 X 0.008 IN.)

1 040 ₽
36

3604-171 VALVE, (0.600 X 0.004 IN.)

VALVE, (0.600 X 0.004 IN.)

1 870 ₽
37

0603-333 VALVE, (0.800 X 0.006 IN.)

VALVE, (0.800 X 0.006 IN.)

2 070 ₽
38

3604-170 WASHER, TOP OUT

WASHER, TOP OUT

3 320 ₽
39

2604-966 WASHER, TOP OUT

WASHER, TOP OUT

710 ₽
40

3603-402 BODY, SHOCK - LOWER

BODY, SHOCK - LOWER

15 590 ₽
41

3603-382 END CAP, SHOCK/RESERVOIR

END CAP, SHOCK/RESERVOIR

29 530 ₽
42

3603-422 PISTON, INTERNAL FLOATING (INC. 43)

PISTON, INTERNAL FLOATING (INC. 43)

10 810 ₽
43

1604-316 ...SCREW, MACHINE W/O-RING

...SCREW, MACHINE W/O-RING

770 ₽
44

3603-392 END CAP, RESERVOIR

END CAP, RESERVOIR

5 190 ₽
45

3603-379 RING, RETAINING

RING, RETAINING

400 ₽
46

3603-388 RESERVOIR

RESERVOIR

16 430 ₽
47

3603-365 DECAL, "PERFORMANCE SERIES"

DECAL, "PERFORMANCE SERIES"

2 700 ₽
48

3603-378 DECAL, RESERVOIR

DECAL, RESERVOIR

2 700 ₽
49

3603-466 CARTRIDGE, DAMPING ADJUSTER

CARTRIDGE, DAMPING ADJUSTER

15 180 ₽
50

3603-385 KNOB, DAMPING ADJUSTER - LOW SPEED

KNOB, DAMPING ADJUSTER - LOW SPEED

610 ₽
51

4639-012 FLUID, FLOAT SHOCK - (8 OZ)

FLUID, FLOAT SHOCK - (8 OZ)

5 200 ₽
52

5639-530 OIL, SHOCK - (1 QT)

OIL, SHOCK - (1 QT)

3 950 ₽
