SUSPENSION REAR - REAR ARM SHOCK ABSORBER для Arctic Cat ZR 6000 R SX (GREEN) [S2015ACDPRUSG] - 2015 года выпуска

№

Артикул

Название
-

2704-638 SHOCK ABSORBER

SHOCK ABSORBER

130 ₽
1

4604-024 EYELET, SHOCK - ASSEMBLY (INC. 2-8)

EYELET, SHOCK - ASSEMBLY (INC. 2-8)

20 380 ₽
2

4604-077 ...SPACER

...SPACER

8 940 ₽
3

3603-399 ...BEARING

...BEARING

3 740 ₽
4

4604-076 ...SLEEVE

...SLEEVE

2 910 ₽
5

4604-022 ...KNOB, DAMPING - EYELET

...KNOB, DAMPING - EYELET

4 150 ₽
6

1604-318 ...O-RING

...O-RING

1 870 ₽
7

1604-315 ...BALL, BLEED

...BALL, BLEED

630 ₽
8

3603-380 ...SPRING

...SPRING

1 870 ₽
9

4604-025 SHAFT, SHOCK

SHAFT, SHOCK

24 540 ₽
10

4604-023 ROD, DAMPING ADJUSTER - ASSEMBLY

ROD, DAMPING ADJUSTER - ASSEMBLY

2 700 ₽
11

2604-953 NEEDLE, DAMPING W/O-RING

NEEDLE, DAMPING W/O-RING

6 650 ₽
12

4604-029 VALVE, CHECK - ASSEMBLY

VALVE, CHECK - ASSEMBLY

13 310 ₽
13

3603-450 END CAP, SHOCK

END CAP, SHOCK

10 810 ₽
14

0604-992 RING, RETAINING

RING, RETAINING

920 ₽
15

3603-451 BEARING ASSEMBLY

BEARING ASSEMBLY

18 510 ₽
16

4604-021 BODY, SHOCK

BODY, SHOCK

16 010 ₽
17

3603-418 DECAL, WARNING

DECAL, WARNING

1 870 ₽
18

4604-027 KIT, REBUILD - SHOCK

KIT, REBUILD - SHOCK

21 000 ₽
19

4604-026 SPACER

SPACER

1 870 ₽
20

2604-449 WASHER, TOP OUT

WASHER, TOP OUT

2 070 ₽
21

4604-130 VALVE, (1.000 X 0.010 IN.)

VALVE, (1.000 X 0.010 IN.)

0 ₽
22

2604-485 VALVE, (1.100 X 0.008 IN.)

VALVE, (1.100 X 0.008 IN.)

1 020 ₽
23

2604-687 VALVE, (1.250 X 0.012 IN.)

VALVE, (1.250 X 0.012 IN.)

1 870 ₽
24

2604-493 VALVE, (1.350 X 0.012 IN.)

VALVE, (1.350 X 0.012 IN.)

1 870 ₽
25

2604-498 VALVE, (1.425 X 0.012 IN.)

VALVE, (1.425 X 0.012 IN.)

1 870 ₽
26

2604-503 VALVE, (1.600 X 0.012 IN.)

VALVE, (1.600 X 0.012 IN.)

1 870 ₽
27

3604-149 VALVE, (1.100 X 0.004 IN.)

VALVE, (1.100 X 0.004 IN.)

1 020 ₽
28

2604-501 VALVE, (1.600 X 0.008 IN.)

VALVE, (1.600 X 0.008 IN.)

1 870 ₽
29

2604-693 VALVE, RING - (1.600 X 0.015 IN.)

VALVE, RING - (1.600 X 0.015 IN.)

2 070 ₽
30

0403-394 PISTON, HIGH-FLOW

PISTON, HIGH-FLOW

10 190 ₽
31

3604-725 O-RING

O-RING

230 ₽
32

3603-413 STRAP, PISTON

STRAP, PISTON

4 360 ₽
33

2604-499 VALVE, (1.425 X 0.015 IN.)

VALVE, (1.425 X 0.015 IN.)

900 ₽
34

3604-624 WASHER, TOP OUT

WASHER, TOP OUT

1 040 ₽
35

3604-184 WASHER, BACKUP

WASHER, BACKUP

2 070 ₽
36

2604-448 NUT

NUT

2 700 ₽
37

3603-448 END CAP, BODY/RESERVOIR

END CAP, BODY/RESERVOIR

29 530 ₽
38

3603-379 RING, RETAINING

RING, RETAINING

400 ₽
39

3603-392 END CAP, RESERVOIR

END CAP, RESERVOIR

5 190 ₽
40

4604-017 KIT, REBUILD - RESERVOIR

KIT, REBUILD - RESERVOIR

13 930 ₽
41

3603-422 PISTON, INTERNAL FLOATING

PISTON, INTERNAL FLOATING

10 810 ₽
42

3603-388 RESERVOIR

RESERVOIR

16 430 ₽
43

3603-365 DECAL, "PERFORMANCE SERIES"

DECAL, "PERFORMANCE SERIES"

2 700 ₽
44

3603-378 DECAL, RESERVOIR

DECAL, RESERVOIR

2 700 ₽
45

3603-466 CARTRIDGE, DAMPING ADJUSTER

CARTRIDGE, DAMPING ADJUSTER

15 180 ₽
46

3603-385 KNOB, DAMPING ADJUSTER - LOW SPEED

KNOB, DAMPING ADJUSTER - LOW SPEED

610 ₽
47

3603-377 SCREW, MACHINE

SCREW, MACHINE

1 870 ₽
48

5639-530 OIL, SHOCK - (1 QT)

OIL, SHOCK - (1 QT)

3 950 ₽
