OIL TANK ASSEMBLY для Arctic Cat ZR 7000 SNO PRO (ORANGE) [S2015ZRUSPUSO] - 2015 года выпуска
-
№АртикулНазвание
-
11770-080 TANK, OILTANK, OIL
-
22670-257 GLASS, SIGHTGLASS, SIGHT
-
31602-213 O-RINGO-RING
-
42602-099 PLUG, DRAIN - (12MM)PLUG, DRAIN - (12MM)
-
52670-287 CAP, TUBECAP, TUBE
-
62670-219 TUBE, OIL TANKTUBE, OIL TANK
-
72670-224 CAP, OIL TANK (INC. 8)CAP, OIL TANK (INC. 8)
-
82670-135 ...SEAL, CAP - OIL TANK...SEAL, CAP - OIL TANK
-
91623-814 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
102670-406 O-RINGO-RING
-
112670-221 FITTING, OIL RETURN - ENGINEFITTING, OIL RETURN - ENGINE
-
121623-969 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
132623-088 CLAMP, HOSECLAMP, HOSE
-
140610-940 HOSE, OILHOSE, OIL
-
152670-286 TUBE, OIL - OIL TANK/ENGINETUBE, OIL - OIL TANK/ENGINE
-
161623-349 CLAMP, HOSECLAMP, HOSE
-
170610-919 HOSE, OILHOSE, OIL
-
181623-182 CLAMP, HOSECLAMP, HOSE
-
191623-939 CLIP, U-NUTCLIP, U-NUT
-
202623-015 CLAMP, ROUTING - (0.875 DIA)CLAMP, ROUTING - (0.875 DIA)
-
210623-784 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
220610-929 HOSE, OILHOSE, OIL
-
230610-790 LOOM, COOLANT HOSE - (5 FT)LOOM, COOLANT HOSE - (5 FT)
-
242670-285 TUBE, OIL - ENGINE/OIL TANKTUBE, OIL - ENGINE/OIL TANK
-
252670-220 FITTING, OIL SUPPLY - ENGINEFITTING, OIL SUPPLY - ENGINE
-
262670-290 O-RINGO-RING
-
272670-222 SCREEN, OIL TANKSCREEN, OIL TANK
-
280673-459 O-RINGO-RING
-
290670-183 O-RINGO-RING
-
302670-288 FITTINGFITTING
-
311623-287 CLAMP, HOSECLAMP, HOSE
-
320610-965 HOSE, OIL - (60MM)HOSE, OIL - (60MM)
-
331623-350 CLAMP, HOSECLAMP, HOSE
-
342670-419 TUBE, OIL - OIL TANK/SEPARATOR TANKTUBE, OIL - OIL TANK/SEPARATOR TANK
-
351770-058 TANK, SEPARATORTANK, SEPARATOR
-
362670-375 TUBE, OIL - SEPARATOR TANK/OIL TANKTUBE, OIL - SEPARATOR TANK/OIL TANK
-
370610-954 HOSE, OILHOSE, OIL
-
382670-374 TUBE, OIL - SEPARATOR TANK/AIR INTAKETUBE, OIL - SEPARATOR TANK/AIR INTAKE
-
390423-357 NUT, STAMPED - (1/4 IN.)NUT, STAMPED - (1/4 IN.)
-
408470-510 SCREW, MACHINESCREW, MACHINE
-
410406-877 BUMPERBUMPER
-
422670-381 SHIELD, HEATSHIELD, HEAT
-
432623-012 GROMMET - (5/8 IN. W X 1 1/32 IN. LG)GROMMET - (5/8 IN. W X 1 1/32 IN. LG)
-
441048-063 SEALANT - (70 ML)SEALANT - (70 ML)
