EXHAUST ASSEMBLY для Arctic Cat ZR 6000 R SX GREEN [S2016ACDPRUSG] - 2016 года выпуска

№

Артикул

Название
1

1712-774 RESONATOR ASSEMBLY

RESONATOR ASSEMBLY

126 250 ₽
2

1612-873 GROMMET

GROMMET

650 ₽
3

1712-796 BRACKET, MOUNTING - LOWER

BRACKET, MOUNTING - LOWER

3 320 ₽
4

1623-241 RIVET

RIVET

290 ₽
5

1712-800 BRACKET, MOUNTING - UPPER REAR

BRACKET, MOUNTING - UPPER REAR

3 110 ₽
6

0412-577 BUSHING

BUSHING

440 ₽
7

0607-447 CABLE

CABLE

810 ₽
8

8060-504 RIVET

RIVET

40 ₽
9

2612-347 WASHER, RESONATOR

WASHER, RESONATOR

480 ₽
10

0605-283 CLIP, HAIRPIN

CLIP, HAIRPIN

190 ₽
11

1623-814 SCREW, MACHINE

SCREW, MACHINE

170 ₽
12

8408-625 SCREW, CAP

SCREW, CAP

90 ₽
13

1712-798 BRACKET, MOUNTING - UPPER FRONT

BRACKET, MOUNTING - UPPER FRONT

4 570 ₽
14

8427-602 NUT, LOCK

NUT, LOCK

440 ₽
15

1612-323 GASKET, EXHAUST PIPE

GASKET, EXHAUST PIPE

4 360 ₽
16

0612-471 SPRING, EXTENSION

SPRING, EXTENSION

1 870 ₽
17

0630-330 SENSOR, EXHAUST TEMP

SENSOR, EXHAUST TEMP

31 820 ₽
18

0123-811 TIE, CABLE - 4 IN.

TIE, CABLE - 4 IN.

40 ₽
19

1712-974 CHAMBER, EXPANSION (INC. 20-26)

CHAMBER, EXPANSION (INC. 20-26)

130 ₽
20

1712-975 ...CHAMBER, EXPANSION

...CHAMBER, EXPANSION

130 ₽
21

2612-735 ...COVER, EXPANSION CHAMBER - UPPER

...COVER, EXPANSION CHAMBER - UPPER

17 470 ₽
22

2612-737 ...PACKING, EXPANSION CHAMBER - UPPER

...PACKING, EXPANSION CHAMBER - UPPER

2 700 ₽
23

2612-738 ...PACKING, EXPANSION CHAMBER - LOWER

...PACKING, EXPANSION CHAMBER - LOWER

2 700 ₽
24

2612-736 ...COVER, EXPANSION CHAMBER - LOWER

...COVER, EXPANSION CHAMBER - LOWER

11 230 ₽
25

0624-552 ...TIE, PERFORATED BAND - 5 FT

...TIE, PERFORATED BAND - 5 FT

3 110 ₽
25

0624-541 ...TIE, PERFORATED BAND - 25 FT

...TIE, PERFORATED BAND - 25 FT

16 430 ₽
26

1612-178 ...SPRING, EXHAUST

...SPRING, EXHAUST

580 ₽
27

2612-615 SEAL, EXHAUST PIPE

SEAL, EXHAUST PIPE

4 780 ₽
28

1712-811 MANIFOLD, EXHAUST

MANIFOLD, EXHAUST

33 480 ₽
29

0612-668 SPRING, EXTENSION

SPRING, EXTENSION

710 ₽
