02- Air Intake System для BRP RX DI (LE), 5583/5584/5585 - 2002
-
№АртикулНазвание
-
1273000123 Air Silencer SupportAir Silencer Support
-
2205063560 Socket Head Screw M6 x 35Socket Head Screw M6 x 35
-
3234061600 Flat Washer 6 mmFlat Washer 6 mm
-
4270600028 Soleno‹de ValveSoleno‹de Valve
-
5273000209 Air Silencer. Includes 5 - 8.Air Silencer. Includes 5 - 8.
-
7415080100 Line (Meter)Line (Meter)
-
8273000181 ConnectorConnector
-
9293800060 Loctite 243, 10 mlLoctite 243, 10 ml
-
10293250122 GasketGasket
-
11275500454 Check ValveCheck Valve
-
12293250065 O-RingO-Ring
-
13293650079 Norma Gear ClampNorma Gear Clamp
-
14270600023 Air Intake AdaptorAir Intake Adaptor
-
15270600022 Pressure Hose. Includes 15 - 16.Pressure Hose. Includes 15 - 16.
-
16293300070 O-RingO-Ring
-
17293750001 Tie Rap 94 mmTie Rap 94 mm
-
18270000374 Hose 4.3 mm (Meter)Hose 4.3 mm (Meter)
-
19207181260 Hex. Screw M8 x 12Hex. Screw M8 x 12
-
20274000839 IsolatorIsolator
-
21250400015 Hair PinHair Pin
-
22234082600 Flat Washer 8 mmFlat Washer 8 mm
-
23293720064 GrommetGrommet
-
24275500398 Check ValveCheck Valve
-
25270000471 Hose 4.3 mm (Meter)Hose 4.3 mm (Meter)
-
26293650100 Gear Clamp OetikerGear Clamp Oetiker
-
27232561600 Elastic Stop Nut M6Elastic Stop Nut M6
-
28273000163 Intake Adaptor (PTO)Intake Adaptor (PTO)
-
29234062600 Flat Washer 6 mmFlat Washer 6 mm
-
30232561600 Elastic Stop Nut M6Elastic Stop Nut M6
-
31272000074 SpacerSpacer
-
32278001260 InsulatorInsulator
-
33207063560 Hex. Screw M6 x 35Hex. Screw M6 x 35
-
34273000164 Intake Adaptor (MAG)Intake Adaptor (MAG)
-
35273000151 Air Duct (PTO)Air Duct (PTO)
-
36273000150 Air Duct (MAG)Air Duct (MAG)
-
37273000165 Protector PadProtector Pad
-
38293750002 Tie Rap 130 mmTie Rap 130 mm
-
39273000204 Support PlateSupport Plate
-
40293720052 GrommetGrommet
-
41293710068 T-FittingT-Fitting
-
42270600024 Female AdaptorFemale Adaptor
-
43270600043 Throttle Body Ass'y. Includes 43 - 67.Throttle Body Ass'y. Includes 43 - 67.
-
44270600026 Lower SupportLower Support
-
45270600045 Support Ass'y. Includes 45 - 46.Support Ass'y. Includes 45 - 46.
-
46270600046 Latch BracketLatch Bracket
-
47205051060 Socket Head Screw M5 x 10Socket Head Screw M5 x 10
-
48270600048 SpringSpring
-
49270600032 Throttle Body (PTO). Includes 49 - 56.Throttle Body (PTO). Includes 49 - 56.
-
50270600034 Throttle Lever Ass'yThrottle Lever Ass'y
-
51270600039 Potentiometer ScrewPotentiometer Screw
-
52234161601 Lock Washer M6Lock Washer M6
-
53232061600 Hex. Nut M6Hex. Nut M6
-
54270600036 Spring GuideSpring Guide
-
55270600037 SpringSpring
-
56270000251 Position SensorPosition Sensor
-
57270600033 Throttle Body (MAG). Includes 57 - 64.Throttle Body (MAG). Includes 57 - 64.
-
58270600035 Pick-Up LeverPick-Up Lever
-
59270600039 Potentiometer ScrewPotentiometer Screw
-
60234161601 Lock Washer 6 mmLock Washer 6 mm
-
61232061600 Hex. Nut M6Hex. Nut M6
-
62270600036 Spring GuideSpring Guide
-
63270600038 SpringSpring
-
64270000251 Position SensorPosition Sensor
-
65270600049 Idle ScrewIdle Screw
-
66270600050 Cover (Loctite Ultra Grey)Cover (Loctite Ultra Grey)
-
67270600047 Screw AdjusterScrew Adjuster
-
68207341260 Hex. Screw M4 x 12 (Scotch Grip)Hex. Screw M4 x 12 (Scotch Grip)
-
69234042600 Flat Washer 4 mmFlat Washer 4 mm
-
70270600021 Air Intake HoseAir Intake Hose
-
71415116600 Protective Shield (Meter)Protective Shield (Meter)
-
72414115200 Tie RapTie Rap
-
73293650130 Tridon GearTridon Gear
-
74293650131 Tridon GearTridon Gear
-
75234161601 Lock Washer 6 mmLock Washer 6 mm
-
76270000544 O-RingO-Ring
-
77293100011 Tubing 1'' (meter)Tubing 1'' (meter)
-
78278001166 Module ProtectorModule Protector
