02- Oil System для BRP Lynx Adventure GT 600 E-TEC - 2014
-
№АртикулНазвание
-
1519000251 Oil TankOil Tank
-
2515176978 Level SensorLevel Sensor
-
3519000273 CapCap
-
4519000216 CapCap
-
6293650043 Clamp OetikerClamp Oetiker
-
7250000331 Forming Screw M6 x 20Forming Screw M6 x 20
-
8224061201 Flat WasherFlat Washer
-
9519000179 BracketBracket
-
10241151640 Screw Hex. Flange K50 x 16Screw Hex. Flange K50 x 16
-
11414554800 Spring ClampSpring Clamp
-
12519000272 HoseHose
-
13415079900 Protector TubeProtector Tube
-
14519000281 Oil PumpOil Pump
-
15293650099 Crimp ClampCrimp Clamp
-
16519000271 BracketBracket
-
17293650100 ClampClamp
-
18519000182 HoseHose
-
19519000182 HoseHose
-
20519000184 HoseHose
-
21519000184 HoseHose
-
22515175442 Protector TubeProtector Tube
-
23515175442 Protector TubeProtector Tube
-
24515175442 Protector TubeProtector Tube
-
25515175442 Protector TubeProtector Tube
-
26519000245 BracketBracket
-
27293750002 Tie Rap 142mmTie Rap 142mm
-
28516005528 Warning DecalWarning Decal
-
29516004648 Protect DecalProtect Decal
